Application of IMC-PID in the Hydraulic Headbox Total Pressure Control

Abstract:

It is very difficult to obtain perfect performance to apply the conventional PID (Proportional-Integral-Derivative) controller, because hydraulic headbox needs high precision total pressure control. Transfer function of total pressure control system was identified by using the direct identification method which is based on the least square method for the first-order plus delay time model. Then combined with IMC (Internal-Model-control) –PID method, an IMC-PID controller was designed, which is simple and only needed to adjust one parameter-the time constant of low pass filter. Acceptable performance can also be obtained by tuning time constant of the low pass filter when the model doesn't match with the real process. The algorithm was applied to total pressure control system of hydraulic headbox. Simulation and practical application show that, IMC-PID is of strong robustness and good dynamic characteristics. Finally, the control system is implemented by S7-300 PLC.

You might also be interested in these eBooks

Material Science and Engineering Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 462)

Pages:

789-795

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.462.789

Citation:

Cite this paper

Online since:

February 2012

Authors:

Wei Tang, Xu Zhong Niu, Wen Juan Shan

Keywords:

Direct Identification, IMC-PID, S7-300 PLC, Total Pressure Control

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Garcia C E, Morari M, in: Internal model control: A unifying review and some new results. Ind Eng Chem Process Des Dev. 1982 : 308～323.

DOI: 10.1021/i200017a016

Google Scholar

[2] Rivera D E, Morari M, Skogested S, in: Inernal model control PID controller design. Ind Eng Chem Process Des Dev, 1986 : 252～265.

DOI: 10.1021/i200032a041

Google Scholar

[3] Skogestad S, in: Simple Analytic Rules for Model Reduction and PID Controller Tuning. Process Control 2003 : 291～309.

DOI: 10.1016/s0959-1524(02)00062-8

Google Scholar

[4] Wei Tang, Mengxiao Wang, Minghui Li, in: The development Summary of paper machine headbox, " 2005 : 132～136.

Google Scholar

[5] Min Li, in: Application of adaptive IMC-PID controller in temperature control of the shuttle kiln. Automation and Instrumentation, 2004 : 46～48.

Google Scholar

[6] Li Fan, Hongquan Lin, Dongjie Gao in: Continuous process control model was directly identificated and applicated. used. Control Engineering, 2006 : 310～313.

Google Scholar

[7] Xiaofeng Gong, Jinchang Gao, Chunhui Zhou, in: Tuning method of PID controller in delay system. Control and Decision, (1998).

Google Scholar
