Design of Digital Controllers for Permanent Magnet Torque Motors

Abstract:

The design of control system can be divided into two steps. The plant has to be converting into mathematical model form, so that its behavior can be analyzed. Then an appropriate controller has to be design in order to get the desired response of the controlled system. In this paper, the linear model of a Permanent magnet torque motor (PMTM) is considered and three controllers, digital PID controller with two forms of positional and velocity, a deadbeat controller and pole placement controller method are designed and due to a comparing between their, the best controller for this kind of plants will be chosen.

• Periodical: Advanced Materials Research (Volumes 463-464)
• Pages: 1219-1223
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.463-464.1219
• Online since: February 2012
• Authors: M. Ebrahimi, Seyed Ali Jazayeri
• Keywords: Deadbeat, Digital PID, Electro Hydraulic, Permanent Magnet Torque Motor, Pole Placement

References

[1] Theory and application of servo valves. Dynamic testing equipment. Inc 734 847 2606.

[2] I.R. Smith, J.G. Kettleborough and Y. Zhang: Simplified modeling and dynamic analysis of a Laws' relay actuator, Department of Electronic and Electrical Engineering, Loughborough University, Loughborough.

[3] K. Ogata: Discrete time control systems (Prentice- Hall International, Inc., 1990).

[4] I. Ahmed: Implementation of PID and Deadbeat Controllers with the TMS320. APPLICATION REPORT: SPRA083.
