Bending-Torsional Flutter of a Composite Rectangular Cantilever Wing Subjected to Engine Thrust

Abstract:

The bending-torsional flutter characteristics of a cantilever composite wing subjected to engine thrust are presented. The engine thrust modeled as a follower force and the wing modeled as a two degree of freedom beam. In order to consider the spanwise and chordwise location and the properties of the engine location, the generalized function theory is used. Unsteady Theodorsen aerodynamic theory in time domain, is used. The general laminate composite theory is used for modeling the effects of the ply angles on the flutter boundary. The Ritz method is subsequently applied to convert the partial differential equations into a set of ordinary differential equations. In order to precisely consider the location of the engine Dirac delta function is used. Moreover, the numerical results are compared with the published results and excellent agreement is observed. Numerical results highlighting the effect of engine thrust on the wing instability, is presented.

• Periodical: Advanced Materials Research (Volumes 463-464)
• Pages: 1568-1572
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.463-464.1568
• Online since: February 2012
• Authors: Mohammad Reza Amoozgar, Saied Irani
• Keywords: Composite Wing, Flutter Boundary, Follower Force, Unsteady Aerodynamic

References

[1] Q.H. Zue and H.L. Schreyer: Flutter and divergence instability of non-conservative beams and plates, International Journal of Solids and Structures, (1996), pp.1355-1367.

DOI: 10.1016/0020-7683(95)00097-6

[2] M. Goland: The flutter of a uniform cantilever wing, Journal of Applied Mechanics, (1945), pp.197-208.

[3] M. Goland and Y.L. Luke: The flutter of a uniform wing with tip weights, Journal of Applied Mechanics, (1948), pp.13-20.

DOI: 10.1115/1.4009753

[4] H.L. Runyan and C.E. Watkins: Flutter of a uniform wing with an arbitrary placed mass according to a differential equation analysis and a comparison with experminet, NASA Technical Report, (1949), NACA TN 1848.

[5] I. Lottati: Aeroelastic stability characteristics of a composite swept wing with tip weights for an unrestrained vehicle, Journal of Aircraft, (1987), pp.793-802.

DOI: 10.2514/3.45523

[6] F.H. Gern and L. Librescu: Static and dynamic aeroelasticity of advanced aircraft wing carrying external stores, AIAA Journal, (1998), pp.1121-1129.

DOI: 10.2514/3.13944

[7] F.H. Gern and L. Librescu: Effects of externally mounted stores on aeroelasticity of advanced aircraft wings, Journal of Aerospace Science and Technology, (1998), pp.321-333.

DOI: 10.1016/s1270-9638(98)80008-4

[8] S. Na and L. Librescu: Dynamic response of adaptive cantilevers carrying external stores and subjected o blast loading, Journal of Sound and Vibration, (2000), pp.1039-1055.

DOI: 10.1006/jsvi.1999.2627

[9] W.T. Feldt and G. Hermann: Bending-torsional flutter of a cantilevered wing containing a tip mass and subjected to a transverse follower force, Journal of the Franklin Institude, (1974), pp.465-478.

DOI: 10.1016/0016-0032(74)90123-9

[10] S.A. Fazelzadeh, A. Mazidi and H. Kalantari: Bending-torsional flutter of wings with an attached mass subjected to a folower force, Journal of Sound and Vibration, (2009), pp.148-162.

DOI: 10.1016/j.jsv.2009.01.002

[11] S.J. Guo, J.R. Banerjee and C.W. Cheung: The effect of laminate lay-up on the flutter speed of composite wings, Journal of Aerospace Engineering, (2003), pp.115-122.

DOI: 10.1243/095441003322297225

[12] D.H. Hodges, E.H. Dowell: Nonlinear equations of motion for the elastic bending and torsion of twisted non-uniform rotor blades, NASA Technical Report, (1974), NASA TN D-7810.

[13] M.J. Patil and D.H. Hodges: Limit-cycle oscillation in high-aspect-ratio wings, Journal of Fluids and Structures, (2001), pp.107-132.

DOI: 10.1006/jfls.2000.0329

[14] D.H. Hodges, M.J. Patil and S. Chae: Effect of thrust on bending-torsion flutter of wings, Journal of Aircraft, (2002), pp.371-379.

DOI: 10.2514/2.2937
