Research and Design of Front Located Hysteroscopy

Abstract:

This paper first introduces the recent development of the popular hysteroscopy, the international minimally invasive diagnosis instrument, and then analyzes the lighting and video of hysteroscopy. According to high energy consumption of common hysteroscopy, front located hysteroscopy system is put forward. The principles, the lens structure, the manufacture process of lens prototype, the trial manufacturing process of power box are all discussed in this paper. It is the first time that prototype has been design and tested in domestic. In the normal conditions, the energy consumption decreased by 299/300. And the volume, the weight, and the price of the designed front located hysteroscopy are greatly reduced. Moreover, tests show that it can apply to special conditions such as the disaster relief field and field operation.

• Periodical: Advanced Materials Research (Volumes 466-467)
• Pages: 1055-1059
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.466-467.1055
• Online since: February 2012
• Authors: Bo Xiang, Ying Jie Kang, Xiu Ying Wang, Kun Dai, Yao Dai
• Keywords: Cameras, High Brightness Leds, Hysteroscopy, Power Box

References

[1] The 64th session of China international medical equipment exposition exhibition [M/CD]. Beijing. National Medicine Lilan Group. 2010, 10.

[2] Q. S. Zhang. Selected LED Applied Circuit [M]. Beijing. mechanical industry press, 2010, 2-21.

[3] GB50034-2004, building lighting design standard [S].

[4] Instruction for YB4180 series transistor characteristics graphics instrument [Z]. Yang: Jiangsu Yangzhong Lvyang electrical equipment Co. LTD, (2004).

[5] W. P Na. The Selection and Application of General Integrated Circuit [M]. Beijing. people's wiley&sons press, 2004, 129-151.

[6] China metrology press. New Edition for Collection of Electronic Circuit [M] . Beijing. China Met.
