Parametric Modeling and Finite Element Analysis of the Extruder Key Components Based on Pro/E and ANSYS

Abstract:

The extruder key components consist of extrusion-screw, sleeve and nozzle. Its structure and size decides extrusion effects of the extruder, even to the capability of the whole machine. In this paper, the 3D entity modeling of the extruder key components were established by using the parametric design software of Pro/Engineer, then it was transferred into data that will be used in finite element analysis. The stress analysis was carried out by ANSYS which software of finite element analysis. The results showed that strength of the extrusion-screw, sleeve and nozzle meet the design requirements. Parametric modeling and finite element analysis was the effective way for optimal design of the extruder.

• Periodical: Advanced Materials Research (Volumes 466-467)
• Pages: 572-576
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.466-467.572
• Online since: February 2012
• Authors: Hong Li Wang, Yue Shao
• Keywords: Extruder, Finite Element Analysis (FEA), Parametric Modeling

References

[1] Wang Hongli, Zhang Zuli, Bai Xiaohu. Techniques and Mechanisms of Extruding Process of Soybean. Journal of agricultural mechanization research, Vol. 1 (2006), p.85.

[2] Wang Hongli, Zhang Zuli, Bai Xiaohu. Optimal design of structural and processing parameters of extruder based on MATLAB. Food Machinery, Vol . 4(2003)p.28.

[3] Shao Jiang, Li Shiguo. Connection method and Applications of Pro / E and ANSYS. Mechanical Design, Vol. 9(2004), p.58.

[4] Zhao Haifeng, Jiang Di. ANSYS8. 0 examples of engineering structures. Beijing: China Railroad Press(2004).

[5] Zhong Riming. Pro / ENGINEER Wildfire3. 0 examples of mechanical design tutorial. Beijing: Tsinghua University Press( 2007).

[6] Wan Qichao . Structure, thermal, motion analysis and typical example of Pro / ENGINEER. Beijing: Electronic Industry Press(2008).

[7] Zhu Lingyun, Li Bin. Pro / ENGINEER Wildfire Getting Started Guide. Beijing: Posts & Telecom Press(2003).

[8] Zhang Zhaohui. ANSYS engineering sample entry and increase. Beijing: Tsinghua University Press(2004).
