Control System of Automotive Transmission Test Line Based on PLC and HMI

Abstract:

Utomotive Transmission Test Line Is One of Sub-lines of Automotive Transmission Assembly Line Used for Testing the Quality of Assembly. some Automotive Transmission Enterprise Is Taken as Research Content and Application Background. this Paper Puts Forward a Control System of Automotive Transmission Test Line Based on Wincc Flexible and S7-300PLC.Here Contents Including Program Planning, Supervisory System Developing, Control System Programming and Communication Network Configuring Are Shown. by Using RFID Information Collection of the Online Products Is Achieved. Besides, Remote Data Acquisition and Processing Is Carried Out by Using Profibus-DP. the Control System Represents Advantages such as Good Interface, Well-staged Control Program, Satisfactory Stability and High Quality of Automation.

• Periodical: Advanced Materials Research (Volumes 466-467)
• Pages: 561-566
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.466-467.561
• Online since: February 2012
• Authors: Gao Peng, Shu Hong Chen, Jun Wu
• Keywords: Assembly, Control System, S7-300PLC, Transmission, WinCC Flexible

References

[1] Xisheng LV, Haibo SHI, Bo SHI and Chongjun SUN, Integrated control system of gearbox test loop line, Computer Engineering, 20th ed, vol. 35, p.28–33, (2009).

[2] Hui GAO, Automotive transmission assembly line, Technolygy and Market, 6th ed, vol. 16, p.107, (2009).

[3] Yang SHEN, Study on systematic integration of automobile engine assembly line, Mechanical Institute of Science and Technology, (2006).

[4] Yangyang YOU, Based on the PLC control system design and realization of car body-in-white welding manufaeture line, " Chang, anUniversity, 209.

[5] Yajun LIU, Application of HMI Software Winccflexible of SIEMENS in the Straightening Machine, Shanxi Metallurgy, 1st ed, pp.37-39, (2010).

[6] Tao LIU, Research on the application of fieldbus control teehnology for automobile assembly automation, Chongqing University, (2001).
