Optical 3D Scanning of Small Parts

Abstract:

The paper deals with the investigation of 3D digitizing of small parts specifically by optical 3D scanner GOM ATOS TripleScan. The paper shortly illustrates the general concept of Reverse Engineering, which includes also the 3D scanning. The paper also describes the optical 3D scanner GOM ATOS TripleScan and a three-dimensional model obtaining procedure by means of this scanner. In the main part of the paper the concrete 3D scanning process of chosen individual objects is described (clips, ball nose end mill, screw drill, coin). Their shape and size were specific and distinct, therefore it was possible to test and compare particular digitizing attributes. The problems that occurred during 3D digitizing of individual parts are step by step discussed and solved.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 2269-2273
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.2269
• Online since: February 2012
• Authors: Ladislav Morovič, Peter Pokorný
• Keywords: 3D Digitizing, GOM ATOS Triplescan, Optical 3D Scanning, Reverse Engineering (RE), Small Parts
