Profile Study of Formed Milling Cutter for Screw Based on Non-Instantaneous Envelope Method

Abstract:

Through analyzing the shape of screw of oil extraction progressing cavity pump, the spiral surface equation of screw was established; and from the relative motion between formed milling cutter and screw, the basic profile equation of formed milling cutter was established with the method of non-instantaneous envelope. According to the actual use of formed milling cutter, aim at the problem of wear for formed milling cutter, established profile equation of front cutting edge and constant back cutting edge, and finally to get a complete profile equation of formed milling cutter. The correctness of milling cutter profile is ensured by interference checking for profile equation of formed milling cutter. The profile equation of formed milling cutter provides a theoretical foundation for the design and manufacture, and it would have great significance to the actual production.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 2332-2337
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.2332
• Online since: February 2012
• Authors: Jin Wei Fan, Yun Li, Xiao Feng Wang
• Keywords: Cutting Edge, Formed Milling Cutter, Non-Instantaneous Envelope, Profile Equation, Screw
