Design and Fabrication of the Superabrasive Grinding Wheel with Phyllotactic Pattern

Abstract:

In order to achieve the controllability of the abrasive arrangement on the working surface of grinding wheel,a new kind of the superabrasive grinding wheel, which has defined abrasive grain cluster pattern, has been designed based on the phyllotaxis theory of biology, and fabricated with UV lithography method and electroplating technology. The analytical results indicate that the phyllotactic parameters influence on the abrasive arrangement configuration on the work surface of the superabrasive grinding wheel, so as to improve grinding performance of the grinding wheel, increasing the diameter of phyllotactic abrasive grain cluster and decreasing phyllotactic coefficient can increases the abrasive grain density of the surperabrasive grinding wheel surface. Electroplating experimental results show that the reasonable electroplating processes can reduce the faults of defined abrasive arrangement on the superabrasive grinding wheel surface.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 2354-2360
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.2354
• Online since: February 2012
• Authors: Yu Shan Lu, Cheng Yi Zhao, Jun Wang, Yan He, Zhi Hui Kou
• Keywords: Abrasive Grain Cluster, Grinding, Phyllotactic Pattern, Superabrasive Grinding Wheel

References

[1] J.C. Aurich, P. Herzenstiel, H. Sudermann, T. Magg: High-performance dry grinding using a grinding wheel with a defined grain pattern[J]. CIRP Annals-Manufacturing Technology, 2008 57(1):357–362 .

DOI: 10.1016/j.cirp.2008.03.093

[2] J.C. Aurich, O. Braun, G. Wamecke: Development of a superabrasive grinding wheel with defined grain structure using kinematic simulation, CIRP Annals - Manufacturing Technology 2003 52(1):275-280.

DOI: 10.1016/s0007-8506(07)60583-6

[3] P. Koshy, A. Iwasaki, and M. Elbestawi, Surface generation with engineered diamond wheels: insights from simulation, CIRP Annals - Manufacturing Technology, 2003 52(1):271-274.

DOI: 10.1016/s0007-8506(07)60582-4

[4] F.W. Pinto, G.E. Vargas, K. Wegener: Simulation for optimizing grain pattern on engineered grinding tools. CIRP Annals - Manufacturing Technology, 200857(1): 353–356.

DOI: 10.1016/j.cirp.2008.03.069

[5] C. Heinzel, K. Rickens: Engineered wheels for grinding of optical glass, CIRP Annals - Manufacturing Technology 2009 58 (1) :315–318 .

DOI: 10.1016/j.cirp.2009.03.096

[6] L. Andres, Carrano and B. Taylor James: Geometric modeling of engineered abrasive processes, Journal of Manufacturing Processes,2005 7(1):17-27.

DOI: 10.1016/s1526-6125(05)70078-5

[7] P.W. Butler-Smith D.A. Axinte,M. Daine: Ordered diamond micro-arrays for ultra-precision grinding—An evaluation in Ti–6Al–4V, International Journal of Machine Tools & Manufacture ，2011 51: 54–66.

DOI: 10.1016/j.ijmachtools.2010.09.006

[8] F.R. Yeatts: A growth-controlled model of the shape of a sunflower head. Department of Physics, Colorado School of Mines, Golden, CO 80401-1887,USA.2003.9

[9] H. Vogel: A better way to construct the sunflower head. Mathematical Biosciences, 1979 44:179–189.

DOI: 10.1016/0025-5564(79)90080-4

[10] H.P. Yuan, H. Gao: The technology of abrasive cluster with controlled distribution and development of its grinding wheel, Dissertation,Dalian University of Technology, China 2006.12.

[11] C.H. Tang: Process of diamond tools by eletroplating.Electroplaing & Finishing, In Chinese. 2004, 23(4):61-64.
