The Application of S7-200 PLC Reactive Compensation Device in Small Substation

Abstract:

In the present rural power grid reconstruction project ,according to the problems of capacitor reactive power compensation in rural small substation. Take a small substation for instance, according to its operation and control method, set the criterion of the capacitor bank switching. A new high reliability, flexible reactive power compensation control device based on s7-200 PLC is designed. It plays an important role in improving the power supply , guaranteeing the quality of voltage, reducing the loss of rural power gid.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 1476-1480
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.1476
• Online since: February 2012
• Authors: Qing He Chu, Wen Si Cao, Zhen Nie
• Keywords: Reactive Power Compensation, Rural Power Grid Reconstruction, S7-200, Small Substation
