Suspension Design and Research for Electric Vehicles with Independent Steering and Driving

Abstract:

A new suspension using double-wishbone and coil spring type structure is designed for four-wheeled independent steering and driving electric automobile. Firstly, the simplified geometric model is built, and the ADAMS is used to set parametric model. Optimization design was carried out upon the suspension guiding mechanism. The design method of suspension spring stiffness and damping coefficient is presented. And the reasonability of the method is verified by simulation and experiment. The created suspension prototype complies with the design requirements. The suspension test-bed is designed, which can complete t various detection experiments during designing.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 1481-1489
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.1481
• Online since: February 2012
• Authors: Zhu Rong Dong, Zhi Jun Deng, Shao Yun Ren, Hao Qiu, Tom Zi Ming Qi
• Keywords: Design, Electric Automobile, Independent Steering Wheel, Research, Suspension

References

[1] FUKAOT, MIYASAKAS, MORIK. Proceedings of Intelligent Transportation Systems. USA: IEEE. (2001) p.502

[2] Guirong Zhuo, Xinbo Chen , Zhuoping Yu, Gang WAN. Journal of Machine Design (In Chinese). Vol.22(2) (2005), p.29

[3] Zhijun Deng, Zhurong Dong, Xiaochun Zhu, Hao Qiu, Deliang Ma, Songhua Hu. China Patent ZL201020182879.3. (2010)

[4] Weidong Guo: Virtual Prototype Technology and Examples of ADAMS Application (Beihang University press, Beijing 2008)

[5] Wangyu Wang: Automobile design (Mechanical Industry Press, Beijing 2000)

[6] Haobin Jiang, Yi Zhang, Yunliang Yuan. Automotive technology (In Chinese). Vol.3 (2007), p.32
