The Study of Three-Phase Numerical Simulation of Molten Bath in EAF Impinged by Supersonic Oxygen Jet

Abstract:

By Fluent 6.3, develop a mathematical model of three-dimensional and three-phase flow in the molten bath of EAF with side accessorial oxygen lance to study the transient phenomena of jet impingement on the molten steel and the molten slag. The simulation result shows, the impingement of the supersonic oxygen jet will cause flow of molten steel and the molten slag by inspiring wave of the molten bath surface from the impinged hollow centre to the bath centre, and will cause vortexes under bath which become the centre of molten steel circumfluence. The velocity of flowing molten steel under the oxygen lance or around furnace wall will be faster than that at the center of bath. With oxygen jet enhance, the frequency of the molten bath surface wave will increase, and the center of vortexes will be more apart from the impingement point of jet and will be lower to the bottom of bath, the number of vortexes will increase and the effect of impingement on molten steel will increase accordingly.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 1750-1756
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.1750
• Online since: February 2012
• Authors: Shao Chun Chen, Rong Zhu, Jing She Li, Chun Lai He
• Keywords: Electric Arc Furnace, Numerical Simulation, Oxygen Jet, Three-Phase Flow

References

[1] Sampaio R S, Jones J, Vieira B J. Hot Metal Strategies for EAF Industry, C, AISTech 2008 Proceedings. Pittsburgh: Association for Iron and Steel Technology, 2008. 743-751.

[2] Opfermann A. Energy Efficiency of Electric Arc Furnaces, C, AISTech 2008 Proceedings. Pittsburgh: Association for Iron and Steel Technology, 2008. 795-808.

[3] Harris C, Holmes G, Ferri M B. Industrial Application of Supersonic Lance: The KT System Numeric Simulation, Operating Practice, Results and Perspectives, C, AISTech 2006 Proceedings. Cleveland: Association for Iron and Steel Technology, 2006. 483-490.

[4] Gates L, Fujimoto K, Okada Y. Installation of Praxair CoJet® Gas Injection System at Sumikin Steel and Other EAFs with Hot Metal Charges, C, AISTech 2008 Proceedings. Pittsburgh: Association for Iron and Steel Technology, 2008. 723-731.

[5] Ersson M, Jonsson L, Tilliander A. Dynamic Coupling of Computational Fluid Dynamics and Thermodynamics Software: Applied on a Top Blown Converter, J, ISIJ Int., 2008, 48(2): 147-153.

DOI: 10.2355/isijinternational.48.147

[6] Asai M, Hijo H, Ito K. Simulation of the Impingement of a Liquid Jet on a Molten Iron Bath Using a Particle Method, J, ISIJ Int., 2009, 49(2): 178-181.

DOI: 10.2355/isijinternational.49.178

[7] Malfa E, Maddalene F, Giavani C, et al. Numerical Simulation of a Supersonic Oxygen Lance for Industrial Application in EAFs, J, MPT International, 2005, 28(2): 44-50.
