The Characteristics of Low Frequency on Detecting Method via Strain Gages

Abstract:

In order to find out the feasibility to obtain dynamics peculiarity in high frequency domain, the dynamic peculiarity on detecting method with strain gages is researched. By modeling and analyzing qualitatively, the characteristics of low frequency are indicated for strain gages sensor system. Comparing with the test signal difference between vibration acceleration sensor and strain gages sensor system at the three domain which are time, amplitude and frequency, the characteristics of low frequency are proved for the one. Therefore while detecting the high frequency dynamic signal with strain gages sensor system, the high frequency information is attenuated, the mostly spectrum information is lost.

• Periodical: Advanced Materials Research (Volumes 482-484)
• Pages: 1161-1164
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.482-484.1161
• Online since: February 2012
• Authors: Xiao Jun Li, Wen Ming Zhu, Yu Guo Wang, Yu Zhang
• Keywords: Characteristics of Low Frequency, Experiment, Modeling, Strain Gages Detecting, Test Technique and Apparatus

References

[1] Y. Zhang: The Research on Simulating Tests of Load Carrying Situation of Ship Shafting with The Influence of Alignment Condition and Shafting Rotation and Propeller Hydrodynamics (Wuhan Water Transportation University, Wuhan China 1986).

[2] Y. Zhang, C. Luo and Z.P. Zhang: To Identify for Diesel Signals with Strong Noise Based on Wavelet. Transactiona of CSICE Vol. 19-4 (2001), p.365 (In Chinese).

[3] C. Luo: Diesel Engine High-pressure Tubing Pressure Signal Detection and Data Processing Based on Wavelet Transform (Changsha Communications University, Changsha China 2000).

[4] The Group of "Rail Vehicle Door System Vibration And Shock Testing And Detection System": Report on Dynamic Load Test of the Train Doors under the Impact Environment (Department of Vehicle Engineering, Nanjing Institute of Technology, Nanjing China 2011).

[5] J. R. Liu, L. Kong and Y. L: Portable Overweight Vehicle Detection System. Journal of Highway And Transportation Research And Developmen Vol. 12-2 (1995), p.21 (In Chinese).

[6] H. Z. Ding: Experimental Techniques (Mechanical Industry Press, Beijing China 1987).

[7] Y. H. Hu: Power Adjustable Car Seat Model and Its Characterization. Journal of Wuhan Institute of Technology Vol. 8-3 (1995), p.25 (In Chinese).

[8] Y. Zhang, Y. G Wang J. H. Xin and P. Jiang: The Test Analysis for Mode of High-Speed Train Door by Considering the Effect of Transient Pressure Wave. Noise And Vibration Control Vol. 31-3 (2011), p.95 (In Chinese).

[9] X. J. LI, Y Zhang, Y. G. WANG, Z. B. Zhang and R. W. Chen: Determining Nature Frequency of High-speed Train Door System via Scanning Frequency Excitation Technique. Journal of Nanjing Institute of Technology(Natural Science Edition) Vol. 9-2 (2011), p.1 (In Chinese).
