The Output Researching of a Cascaded Multilevel Class-D Power Amplifier

Abstract:

A high efficiency switch-mode power amplifier based on a cascaded multicell multilevel circuit topology is introduced in the paper. A multicell topology being operated in a unipolar phase-shifted PWM control to switch-mode amplifier system is introduced. After analysising a single-phase H-bridge unipolar PWM inverter’s output, the paper emphasis on the researching of the output of a Cascaded Multilevel Class-D Power Amplifier. The paper analyzes the advanced characteristic of the cascaded multilevel technique. Then a cascaded multilevel class-D power amplifier is built in the laboratory. The result of measurement shows a good following performance and stability.

• Periodical: Advanced Materials Research (Volumes 482-484)
• Pages: 3-10
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.482-484.3
• Online since: February 2012
• Authors: Guo Hua Xu, Ying Zhang, Ming Dong, Qing De Meng
• Keywords: Class D Amplifier, Harmonic, Multi-Level, Phase-Shifted Modulation

References

[1] Stanley G R, Bradshaw K M. "Precision DC-to-AC power conversion by optimization of the output current waveform-The half-bridge revisited ," In: Proceeding of the 28th IEEE power Electronics Specialists conference, St. Louis, Missouri, USA, , vol.35(1997), pp: 993-999.

DOI: 10.1109/pesc.1997.616848

[2] Isao Takahashi, Kazuki Iways. " High efficiency low harmonic distortion switching type power amplifier using multilevel inverter ," In: Power conversion conference, Osaka, Japan. ( 2002).

DOI: 10.1109/pcc.2002.997543

[3] H. Ertl, J.W. Kolar and F. C. Zach, "Basic considerations and topologies of switched-mode assisted linear power amplifiers,"IEEE Trans .Ind.Electron, vol. 44(1997), pp.116-122.

DOI: 10.1109/41.557506

[4] WU Hong-yang, HE Xiang-ning."Relationspbip between multilevel carrier-based PWM and SVPWM and its applications ," Proceeding of the CESS, vol. 22 ( 2002), pp.10-15

[5] HUO Shao-Cheng, WANG Yong-Ji, "Discrete variable structure controller for a brushless dc motor drive ," Proceeding of the CESS, vol. 24 (2004), pp.96-99.

[6] SONG Jun-ying, LIU Di-chen, CHEN Yun-ping. "Decentralized variable structure control in asynchronized synchronous generator paralleled with synchronous generator," Proceeding of the CESS, vol. 24(2004), pp.172-178.

[7] Hans Ertl, Johann Wkolar. "Analysis of a multilevel multicell switch-mode power amplifier employing the flying-battery concept," IEEE Transactions on Industrial Electronics., vol. 49(2002), pp:816-823.

DOI: 10.1109/tie.2002.801056

[8] Zhang Ying, Li Yaohua, Sheng Xiaosong, "Design of a Cascade Multilevel Class-D Amplifier Based on Dual Feedback Loop Control, " Transactions of china electrotechnical society, vol.20 (2005), pp:80~83.
