Portable Position Sensitive Detector with Outdoor Environment Resolution

Abstract:

This paper presents the design of a portable optical PSD (Position Sensing Detector) for application in outdoor environment. The system is able to measure changes in the position of a light spot emitted by a usual laser device (635-1000nm wavelength) in outdoor environment. A piece of frosted glass is employed as the target to show the light spot, and a narrow-band filter and 1% neutral filter are adopted to reduce the interference from sunlight. The paper uses a pinhole camera to reduce the device volume, but lens distortion with off-the-shelf cameras is significant. The image manipulation circuit corrects the distortion, and displays the light spot center position.

• Periodical: Advanced Materials Research (Volumes 482-484)
• Pages: 767-770
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.482-484.767
• Online since: February 2012
• Authors: Qun Ma, Wen Gang Qin, Shi Liang Ma
• Keywords: Image Distortion, Light Spot Center, Pinhole Camera, PSD

References

[1] J. Zhang, T. Yamaguchi, K. Iwata, H. Kikuta, C.S. Park, Appl. Opt. 42, 5661 (2003)

[2] D.W. Buhler, T.R. Oxland, L.P. Nolte, Med. Eng. Phys. 19, 187

[3] J.T. Wallmark, Proc. IRE Vol. 45(1957), p.474

[4] Ricardo Dolda´n, Eduardo Peralı´as, Alberto Yu´fera, Adoracio´n Rueda, in:Analog Integr Circ Sig Process Vol. 53 (2007), p.109

[5] Wang, A., Qiu, T., Shao, L. Journal of Mathematical Imaging and Vision Vol. 35(2009), p.165

[6] Devernay, F., Faugeras, O. Machine Vision and Applications Vol.13(2001), p.14

[7] Hartley, R., Zisserman, A. Multiple View Geometry in Computer Vision, 2nd edn. Cambridge University Press, Cambridge (2004)
