Influence of Machining Strategies on Surface Roughness in Ball End Milling of Inclined Surfaces

Abstract:

Inclined surfaces are commonly used in the aerospace and die/mold industries. For machining this kind of surfaces, many aspects have to be considered as machinability considerations including milling strategies, machining parameters and etc. In machining, achieving better quality is challenging task. Various tool-path strategies during milling operation leads to variable surface roughness on machined samples. The objective of this study is to analyze different machining strategies in 3-axis milling of a typical curved geometry part. The machining parameters used in this study, are cutting speed, feedrate and stepover. This paper also presents an approach to develop a mathematical model for measuring Scallop height size and distribution for different machining strategies to show that Scallop height size has direct relation with Surface roughness measurements in each strategy. Finally the optimized strategy based on the results was determined.

• Periodical: Advanced Materials Research (Volumes 488-489)
• Pages: 836-840
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.488-489.836
• Online since: March 2012
• Authors: S. Shajari, M.H. Sadeghi, H. Hassanpour, B. Jabbaripour
• Keywords: Inclined Surface, Milling Strategy, Scallop Height, Surface Roughness (SR)

References

[1] C.K. Toh: Cutter path orientations when high-speed finish milling inclined hardened steel. Int‏ Adv‏ Manuf‏ Technol, Vol. 27 (2006), pp.473-480.

DOI: 10.1007/s00170-004-2206-4

[2] C.K. Toh: A study of the effects of cutter path strategies and orientations in milling. Journal of Manufacturing Processes, Vol. 152 (2004), pp.346-356.

DOI: 10.1016/j.jmatprotec.2004.04.382

[3] A.M. Ramos, C. Relvas, J.A. Simoes: The influence of finishing strategies on Texture, roughness and dimensional deviations on the machining of complex surfaces. Journal of Materials Processing Technology, Vol. 136 (2003), pp.209-216.

DOI: 10.1016/s0924-0136(03)00160-2

[4] C.K. Toh: Design, evaluation and optimization of cutter path strategies when high speed machining hardened mould and die materials, Materials And Design. Vol. 26 (2005), pp.517-533.

DOI: 10.1016/j.matdes.2004.07.019

[5] Jenq-Syong Chen, Yung-Kuo Huang, Mao-Son Chen: A study of the surface scallop generating mechanism in the ball-end milling process. International Journal of Machine Tools & Manufacture, Vol. 45 (2005), pp.1077-1084.

DOI: 10.1016/j.ijmachtools.2004.11.019

[6] X.F. Zhang, J. Xie, H.F. Xie, L.H. Li: Experimenal investigation on various tool path strategies influencing surface quality and form accuracy of CNC millied complex free form surface. Int Adv Manuf Technol (2011).

DOI: 10.1007/s00170-011-3515-z
