Study on Automatic Calibration System of Multi-Layered Laminated Thin Film Thermocouple Cutting Temperature Sensor

Abstract:

In cutting temperature survey, in order to reflect the temperature change of cutting area accurately, the cutting tool sensor should have good technical characteristic. In this paper, one kind of automatic calibration system has been developed which could be used to investigate the technical characteristic of the multi-layered laminated thin film thermocouple cutting temperature sensor, this system selects Platinum-chip temperature sensor (concrete model: EN60751) as the standard temperature sensor, uses the AD524 precise amplifier chip building amplifying circuit and compiles the software with LabVIEW. This paper intends to investigate the static characteristic of the multi-layered laminated thin film thermocouple cutting temperature sensor system, the result shows that the Seebeck coefficient is 66.9 μV/°C, and the nonlinear error of fitting is smaller than 0.32%. This research has paved the way for future studying of thin film thermocouple cutting temperature sensor technology characteristic.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 3578-3583
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.3578
• Online since: March 2012
• Authors: Ya Nan Wang, Dong Ming Li, Yun Xian Cui, Rasidi Ibrahim
• Keywords: Automatic Calibration, Cutting Temperature Sensor, Static Characteristic, Thin Film Thermocouple

References

[1] C.Z. Duan, Y.Y. Li, G.H. Li and Y. Zhen, The present status of measuring technique of temperature field during high speed machining, Machinery Design & Manufacture. 4 (2008) 212-214.

[2] J.X. Zhang, Question Answering of Application and Maintenance & Calibration Technology of Thermocouple, Chinese Press of Measurement, China, (2003).

[3] Y.X. Cui, B.Y. Sun, Development of multilayer composition thin film thermocouple cutting temperature sensor based on magnetron sputtering, Advanced Material Research. 69-70 (2009) 515-519.

DOI: 10.4028/www.scientific.net/amr.69-70.515

[4] Y.X. Cui, D.S. Yang, Q.Y. Zeng, Characterization of NiCr/NiSi functional thin films on temperature measurement of cutter sensor. Key Engineering Materials. 431-432 (2010) 535-538.

DOI: 10.4028/www.scientific.net/kem.431-432.535

[5] B.Y. Sun, Y.X. Cui, The method of testing transient cutting temperature by multi-layered laminated thin film thermocouple sensor, patent number: ZL200810012355. 7.
