Residual Stresses Distributions within Thin-Walled Ceramic-Metal Seal

Abstract:

Due to significant difference of thermal expansion coefficients between ceramic and metal, the residual stresses are deemed to be induced into the interior of matrix composites within the ceramic-metal seal systems. Many investigations of the residual stresses distributions on dissimilar solid materials joints so far have been carried out theoretically and experimentally, whereas ones of the residual stresses distributions within the thin-walled ceramic-metal seal systems are rarely performed. In order to obtain information for improving their seal structures in the future, the residual stresses distributions resulted from the thermal expansion behavior in the typical configuration of the thin-walled ceramic-metal seal are investigated by theoretical formulae, experimental observation and finite element method (FEM) simulation in this paper. The changing trends of the computational results of the residual stresses distributions agree with the experimental results of the measurement with X-ray diffractometer. The overall residual stresses are found to increase drastically near the welding interfaces. The highest tensile stress occurs at the outer surfaces of the ceramic near the welding interfaces.

• Periodical: Advanced Materials Research (Volumes 503-504)
• Pages: 428-431
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.503-504.428
• Online since: April 2012
• Authors: Guo Liang Zhang, Lei Shi, Da Zhi Jin
• Keywords: FEM Simulation, Residual Stresses Distributions, Thermal Expansion, Thin-Walled Ceramic-Metal Seal, X-Ray Diffractometer
