Finite Element Analysis and Framework Improvement of the Truck Frame

Abstract:

Based on the way of the Finite Element Method (FEM), this paper researches on the three dimensional frame of the truck by analyzing the frame's relevant data including safety factors, maximum stress, maximum displacement position, strain. Through the analysis on the FEM computation results, the frames framework improvement design are supplied. Finally, for testifing the feasibility and practicality of improved frame, this paper simulated frame working under three different conditions which are the full-loaded condition, the right-side load condition and the back-side load condition, and warranted the final summary by contrasting measured relevant data

• Periodical: Advanced Materials Research (Volume 510)
• Pages: 28-33
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.510.28
• Online since: April 2012
• Authors: Yi Jun Wang, Hong Juan Ren, Qi Sun, Jia Lin Lu
• Keywords: FEM Analysis, Frame of the Truck, Framework Improvement Design

References

[1] Dong Zhiming and Zhao Yanjun, in: Concrete mixer truck subframe of stress analysis and structural optimization[J], Special Vehicle. 47-49 (2008).

[2] Liu Hongwen: Mechanics of Materials[J], Higher Education Press, Bejing (2004).

[3] Zhong Peisi: Truck frame based on ANSYS finite element static analysis, Shandong University of Technology (2008).

[4] Yu Chuanwen: Heavy-duty truck frame structure of the finite element simulation and optimization[D], Jilin University, Changchun (2005).

[5] Gao Weimin and Wang Hongyan, in : Finite element method structural analysis of vehicle[J], Automotive Research & Development , 30-32(2000).
