Turning Dynamics of Series Hybrid Power All-Terrain Vehicle

Abstract:

The complex and unstructured working environment of all-terrain vehicle cause large resistance when they are turning. The turning power which affects a lot on the mobility of all-terrain vehicle is much larger than the power in running straight. In this paper, a series hybrid power system of an all-terrain fire robot was discussed, the turning model of the robot is simplified to 2D mechanical model, force analysis was made, a power formula in which the power is only related to the drag coefficient and relative turning radius was derived, and a dynamic model based on the driving power of lateral side and the braking power of medial side has been set up, simulation has been made in the condition of paddy field, hard soil road and asphalt road, the simulation reults shows the characteristic curve of driving power and baking power in turning, and the extreme power needed in turnning have been found.

• Periodical: Advanced Materials Research (Volumes 512-515)
• Pages: 2620-2624
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.512-515.2620
• Online since: May 2012
• Authors: Shu Fang, Zhen Wei Zhang, Lei Zhang
• Keywords: All-Terrain Vehicle, Fire Robot, Series Hybrid Power, Turning Dynamics

References

[1] Brad Graham, Kathy McGowan in: Build Your Own All-Terrain Robot, Publications/ IBT Glabal, NY (2004), in press.

[2] Pierre Lamon, in: 3D-Position Tracking and Control for All-Terrain Robots, edited by Bruno Siciliano, Oussama Khatib, Frans Groen, Publications/Springer-Verlag Berlin Heideberg, Berlin(2010), in press.

[3] Zixin Cai, in: Robotics, Publications/Tsinghua University Press, Beijing(2009), in press.

[4] Information on http://www.cmu.edu/cmnews/extra/060428_crusher.html.

[5] Information on http://www.militaryfactory.com/armor/detail.asp?armor_id=314.

[6] ZHAO Zhiguo, HE Ning, ZHU Yang, YU Zhuoping: Mode Transition Control for Four Wheel Drive Hybrid Electric Car. Journal of Mechanical Engineering. Vol.47(2011), p.100.

DOI: 10.3901/jme.2011.04.100

[7] Brad Goodell: Electrothermal Chemical (ETC) Armament System Integration Into a Combat Vehicle. IEEE TRANSACTIONS ON MAGNETICS, Vol. 43(2007).

DOI: 10.1109/tmag.2006.887524

[8] Hohl Guenter H: Military Terrain vehicle. Journal of Terramehanics, Vol. 44(2007).

[9] Faxian Ding, in: Dynamics of Tracked Armored Vehicle Suspension System, Publications/ National Defence Industry Press, Beijing(2004), in press.

[10] Yinchun Sun, Chengning Zhang, in: Technologies for the Hybrid Electric Drive System of Armored Vehicle, Publications/ National Defence Industry Press, Beijing(2008), in press.
