Design and Realization of ARM-Based Technological LED Display System

Abstract:

the LED dot matrix is an important public information display terminal and the large screen LED display can be applied in many occasions. This article will introduce a LED display which is based on the ARM technology with S3C4510 as the core in an engineering project. In this system, the main control card module is controlled by the S3C4510. The LED display contains the display module, the control drive circuit, and the main control card module as three parts. It is a decoding system that can process a variety of picture files and video files. CPU will remove the demonstration content from the memory which is stored by the user. Then through the display driver circuit, the demonstration content can be changed into the forms signal which the LED display can accept.

• Periodical: Advanced Materials Research (Volumes 512-515)
• Pages: 2697-2700
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.512-515.2697
• Online since: May 2012
• Authors: Xiao Yan Huang, Yong Tie, Shu Hua Li
• Keywords: Control Drive Panel, Display Module, LED Display, Main Control Card Module Visionshow3.8

References

[1] Jizhen Guan, Jiahe Lu, in: The Prospect for the Development of Chinese LED display Technology and Industry, edtied by Laser & Infrared (2003).

[2] Zhiyou Guo, Guanghan Fan, Huiqing Sun, in: LED display brightness and color adjustment method, edtied by Chinese Journal of Liquid Crystals and Displays (2003).

[3] Hongmin Wang, Yudong Guan, Xuequan Chen, Yan Li, in: The Design and Realization for the Controlling System of LED Display Screen Based on ARM7(44B0), edtied by Journal of Harbin University of Science and Technology (2008).

[4] Xiaoping Zhou, Feng He, Pingping Zeng, Tao Huang, in: The Implementing of the Hardware and Software of LED Display Screen and Scan Circuit LED, edited by Circuit Inform
