Study of Microminiature Autonomous Underwater Vehicle Hull Form Based on CFD Technique

Abstract:

Based on CFD technique，this paper discusses the applicability of different turbulence models and mesh partition method which are used to predict the hydrodynamic performance of AUV. Firstly, the hydrodynamic performance prediction method was gotten and was validated, and three different shapes autonomous underwater vehicles were designed. The hydrodynamic performances of the three autonomous underwater vehicles were predicted. Then, the advantage and disadvantage of the four autonomous underwater vehicles were obtained by comparing the resistance and pressure distribution. Based on these, two other AUV hulls were designed which combined the advantages of them, and the hydrodynamic performance was predicted. The calculation results showed that the resistance and hull pressure distribution were improved remarkably comparing with the parent model. The resistance coefficient of optimized hull is reduced by 20% compared to the parent hull.

• Periodical: Advanced Materials Research (Volumes 512-515)
• Pages: 2682-2685
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.512-515.2682
• Online since: May 2012
• Authors: Hai Long Shen, Mo Du, Yu Min Su
• Keywords: AUV, Computational Fluid Dynamics (CFD), Mesh, Resistance Coefficient, Turbulence Model

References

[1] SU Yu-min et al. Development of a small autonomous underwater vehicle controlled by thrusters and fins [J].ROBOT, Vol. 29, No.2 March, 2007:151-154

[2] HU Ke et al. Design and Optimization of Underwater Glider Shape[J].ROBOT, Vol. 27, No.2 March, 2005:108-117

[3] ZHANG Huai-xin et al. Application CFD to compare submarine hull forms [J]. Journal of Ship Mechanic, Vol.10, No.4, Aug., 2006:1-8

[4] Naomi Kato et al. Optimization of Configuration of Autonomous Underwater Vehicle for Inspection of Underwater Cables[C]. Proceedings of the 1998 IEEE International Conference on Robotics & automation Leuven, Belgium .May, 1998:1045-1050

DOI: 10.1109/robot.1998.677227

[5] JongAn Lee et al. Design of Autonomous Underwater Vehicles for Cage Aquafarms[C]. Proceedings of the 2007 IEEE Intelligent Vehicles Symposium Istanbul, Turkey, June 13-15, 2007:938-943

DOI: 10.1109/ivs.2007.4290237

[6] SHEN Hai-long,SU Yu-min, Mesh partition methods for numerical simulation of the flow fields of full form ships[J].Journal of Harbin Engineering University,Vol.29 No.11,Nov.2008:1190-1198

[7] ZHANG Nan, Nan, SHEN Hong-cui, YAO Hui-zhi. Validation of numerical simulation on resistance and flow field of submarine and numerical optimization of submarine hull form[J].Journal of Ship Mechanic, Vol.9, No.1, Feb., 2005:1-13

[8] PAN Zi-ying et al. Research of CFD application in engineering estimation of submarine maneuverability hydrodynamic forces [J]. Journal of Ship Mechanic, Vol.8, No.5, Oct., 2004:42-51

[9] HU Zhi-qiang et al. On numerical computation of viscous hydrodynamics of unmanned underwater vehicle [J].ROBOT, Vol.29, No.5 March, 2007:145-150
