Separation of Butanes and Butylenes by Extractive Distillation with MEK/NFM Mixed Solvent

Abstract:

The feasibility of methyl-ethyl-ketone (MEK) and N-formylmorpholine (NFM) as combination solvent for separation of butanes and butylenes by extractive distillation was investigated. Based on the thermodynamic studies and laboratory data, five butylenes-enriching plants of 30,000 t/a scale were established. The concentration of butylenes product were 97% (wt%), and the recovery of butylenes achieved was 90%. Antifoam agent was employed to prevent the solvent from foaming and worked effectively. As compared with NFM/MOR (morpholine) solvent system or DMF, MEK/NFM solvent system showed advantages such as low bottom temperature of strip column and low toxicity. Further comparison with ACN (acetonitrile) solvent system indicates that MEK/NFM system presented low residue in top production.

• Periodical: Advanced Materials Research (Volumes 524-527)
• Pages: 1876-1880
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.524-527.1876
• Online since: May 2012
• Authors: Xiao Li Han, Yong Mei Feng, Wan Zhong Ren, Xiao Ping Chen, Wen You Xu, Wen Hua Wang
• Keywords: Butylenes, Extractive Distillation (ED), MEK, NFM, Separation

References

[1] I. F.D. Petrole, E. Patent 501,848,A1. (1992)

[2] Z. G. Lei, R. Q. Zhou, and Z. T. Dua: Chem. Eng. J Vol. 85 (2002), p.379

[3] B. Liu, T. Wu, and X. Ch. Du: J. Shandong Chem. Eng Vol. 5 (1999), p.18 (In Chinese)

[4] K. H. Klaus, and P. L. Hubert, U.S. Patent 6,337,429,B1. (2002)

[5] X. J. Yang, X. Yin, and P. K. OuYang: Chin. J. Chem. Eng Vol. 17 (2009), p.27

[6] Zeon Corporation, J. Patent 6-92,876. (1994)

[7] M. Stein: Hydrocarb. Process Vol. 4 (1973), p.139

[8] R. E. Brown, and F. M. Lee, U.S. Patent 4,954,224. (1990)

[9] F. M. Lee, and R. E. Brown, U.S. Patent 4,948,472. (1990)

[10] F. M. Lee: Chem. Eng Vol. 105 (1998), p.112

[11] J. L. Wang: Bachelor Desertion Thesis, Yantai University (2004) (In Chinese)
