Fiber Optic Temperature and Gas Concentration Sensor for Mine Goaf Area Inner Detecting

Abstract:

Spontaneous combustion in coal goaf area is one of major disasters in coal mines. Detection technology based on signature Gas and Temperature is the primary means of spontaneous combustion forecasting of coal goaf area. A real-time remote fire detection system is proposed based on tunable diode laser absorption spectroscopy technology and FBG temperature sensing technology, to achieve valid detect of gas concentration and temperature. The System include fiber mathen concentration sensor and fiber temperature sensor based FBG. The system achieved remote on-line monitoring of gas concentration and temperature in mine goaf, meet the fire forecast need for Coal goaf area. There are obvious advantages Compared with the existing beam tube monitoring system in coal mine.

• Periodical: Advanced Materials Research (Volumes 524-527)
• Pages: 302-305
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.524-527.302
• Online since: May 2012
• Authors: Yu Bin Wei, Xu You Wang, Min Xin, Tong Yu Liu, Chang Wang
• Keywords: Beam Tube Monitoring System, Coal Goaf Area, Coal Mine, Fiber Bragg Grating (FBG), Fiber Mathen Concentration Sensor, Fiber Temperature Sensor, Signature Gas, Spontaneous Combustion, Tunable Diode Laser Absorption Spectroscopy

References

[1] XIAN Xue-fu,WANG Hong-tu,JIANG De-yi.The Summarization of the Investigation on Coal Mine Fire Prevention & Fire Extinguishing Techniques in China[J]. ENGINEERING SCIENCE , 2001 (12) :28-32.

[2] LIANG Yun-tao .Gas index method to predict coal spontaneous combustion[J]. COAL SCIENCE AND TECHNOLOGY , 2008;36:5-8.

[3] TU Xing-hua , LIU Wen-qing , et al . First International Seminar about Environmental Remote Sensing Application Technology Theme Collection . Kunming , 2003. 245.

[4] A Nadezhdinskii, A Berezin, S Chernin, et al. High sensitivity methane analyzer based on tuned near infrared diode laser, Spectrochemica Acta Part A , 55 (10), pp.2083-2089 (1999).

DOI: 10.1016/s1386-1425(99)00080-3

[5] F D Amato, P Mazzinghi, F Castagnoli, Methane analyzer based on TDLAS for measurement s in the lower stratosphere : design and laboratory tests, Appl. Phys. ( B), 75(2), pp.195-202 (2002).

DOI: 10.1007/s00340-002-0981-x

[6] G STEWART, C TANDY, Design of a fiber optic multipoint sensor for gas detection [J ] . Sensors and Actuators (B), pp.227-232 (1998).

[7] W V Drasek, O Charona, K Mulderinka, Multi-functional industrial combustion process monitoring with tunable diode lasers, SPIE 4201, pp.133-141 (2001).

[8] D S Borns, D C Hovde, et al . Early fire sensing using near IR diode laser spectroscopy, SPIE Vol 4817, pp.73-81 (2002).

[9] R Kan, W Liu, Y Zhang,et al. Tunable diode laser absorption spectrometer monitors the ambient methane with high sensitivity, Chinese Journal of Lasers, 32(9) pp.1217-1220 (2005).

[10] Shang ying, Wei yubin, Wang chang, Lei tao, Song zhiqiang, "The Research of Acetylene Gas ConcentrationOn-line Monitoring System Based On Absorption Spectra", Chinese Journal of Sensors and Actuators, pp: 171-174, 2010(2).
