The Rotor’s Modal Analysis of the Vertical Shaft Impact Crusher

Abstract:

Used the Solidedge to bulid the solid model of the Vertical Shaft Impact crusher’s rotor, then it is imported into Ansys for modal analysis, get the former twenty frequency and vibration model, through the twenty color vibration models and vibration animations attained from analysis, the rotor’s dynamic properties and weakness area could be detected directly, to set up the foundmental theory for the structure design.
