Finite Element Simulation on Stress of Steel Sphere Shell

Abstract:

In order to verify correctness of two-dimensional axisymmetric finite element model, this paper carries out axial symmetry analysis of the steel ball shell by ANSYS software and 2-D finite element model is established. The radial and tangential stress distribution is acquired, through comparison with the theoretical solution, both are in good agreement. So it is feasible to simulate the three-dimensional model by finite element axisymmetrical two-dimensional model.

• Periodical: Advanced Materials Research (Volumes 532-533)
• Pages: 297-300
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.532-533.297
• Online since: June 2012
• Authors: Chang Li Song, Jing Ji
• Keywords: ANSYS Software, Axisymmetry, Radial Stress, Tangential Stresss

References

[1] Tao Liu and Fengpeng Yang: Proficient in ANSYS. ( Tsinghua University press, China 2002).

[2] Xin Gu, Ke Wang and Qiwu Dong: Journal of Engineering Thermophysics. Vol. 31(2010), p.1041(in Chinese).

[3] Wenhua Hao: ANSYS Civil Engineering Application Examples (China Water Power Press, China 2005).

[4] Xieyuan Yin: APDL Parametric Finite Element Analysis Technology and Its Application. (China Water Power Press, China 2004).

[5] Zhiguan Xu: Elastic Mechanics. (China Building Industry Press, China 2000).
