The Simulation Analysis of Manipulator Grab the Workpiece Based on PRO/E

Abstract:

The creation method of simulation model of manipulator grab the workpiece is studied based on PRO/E, and the steps how to do the simulation analysis of the manipulator grab the workpiece by PRO/E4.0 software are stated. The results of simulation analysis showed that, in the workpiece quality of 0.08 kg, normal force is about 54.11 N between 0.7 seconds to 7.5 seconds, tangential force is about 0.3924 N between 0.65 seconds to 7.7 seconds, the sum of tangential force of both sides is 0.784 N, it’s exactly equal to the workpiece weight, so that the manipulator can grab the workpiece quickly and accurately.

• Periodical: Advanced Materials Research (Volumes 532-533)
• Pages: 483-487
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.532-533.483
• Online since: June 2012
• Authors: Li Mei Wang, Li Li Zhang, Dong Hua Jiang, Dong Wei Shao
• Keywords: Grab the Workpiece, Manipulator, Pro/E, Simulation Analysis

References

[1] Lin Qingan. Completely master Pro/E wildfires 4. 0 Chinese version comprehensive tutorial. Beijing: electronic industry press, (2009).

[2] Wan Yongmei. Pro/E Wildfire 5. 0 Chinese basic course. Beijing: Tsinghua university press, (2011).

[3] Lin Song. Design method of mechanical Parts. Beijing: Mechanical industry press, (2011).

[4] Zeng Dejiang, Huang Junping. Mechanical basis. Beijing: Mechanical industry press, (2010).

[5] Zhao Fu. Modeling example of mechanical parts. Beijing: China light industry press, (2008).
