The Analysis of Grinding and Polishing for the Tile Planetary Disc Griding Machine

Abstract:

In this study, the polishing machine’s mathematical model of the movement has been established by analysis the several polishing machines’ grinding and polishing process for tile. Then according to the model to simulate the trajectory and compare the grinding grain uniformity and the size of the grinding area. The results show that the disc grinding machine in improving of the efficiency of grinding and grinding grain uniformity is better than the other motions.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 1235-1239
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.1235
• Online since: June 2012
• Authors: Zhe Min Dai, De Sheng Li
• Keywords: Modeling, Planetary Disc Grinding, Polishing, Tile

References

[1] LI Heng-de, The analysis of uniformity of grinding marks for disc grinding, Journal of Mechanical Engineering, (1992)

[2] ZHANG Bo-qing, Ceramic Industry and Equipment [M], China Light Industry Press, (1999)

[3] FENG Hao, The study and modeling of the grinding evenness of ceramic tile polishing, Journal of Ceramics, (1999)

[4] WU Hong-ji, Analysis of path curves of face grinding process on lapping machines, Journal of Dalian University of Technology, (2002)
