Optimization of Torsional Dynamic Properties of Hydraulic Excavator Slewing Transmission Mechanism

Abstract:

A hydraulic excavator is taken as the object to study. Considering the characteristics of slewing transmission mechanism of hydraulic excavator, the torsional vibration equation is established by the finite element method. According to the torsional vibration equation, the effects of the equivalent moment of inertia of working device on the torsional dynamic properties of slewing transmission mechanism are analyzed. Using the optimization theory, the mathematical model is built, which is by means of the equivalent moment of inertia of working device as objective function and by means of the position parameters of the working device as design variables. Based on the mathematical model, the optimization of torsional dynamic properties of slewing transmission mechanism is studied. Finally, a numerical example is presented.

• Periodical: Advanced Materials Research (Volumes 538-541)
• Pages: 2536-2542
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.538-541.2536
• Online since: June 2012
• Authors: Zhao Jun Li, Yu Ling Zhang, Tao Mao, Xu Juan Yang
• Keywords: Dynamic Propertry, Hydraulic Excavator, Optimization, Slewing Transmission Mechanism

References

[1] Zhou Hong-bing, Liu Feng, Chen Gui-fang, etc. Reasearch on braking stability of hydraulic excavator s slewing system[J]. Computer Simulation, 2011, 28(11): 379-382.(in Chinese)

[2] Junli Y, David J E, Peter E D L. A computational intelligent fuzzy model approach for excavator cycle time simulation[J]. Automation in Construction, 2003, 12(6): 725-735.

DOI: 10.1016/s0926-5805(03)00056-6

[3] Li Zhen-ping, Ling Yun, Fan Feng-ming, etc. Study on dynamic characteristic optimization of the planetary gears transmission[J]. Vehicle & Power Technology, 2009, (1): 21-24. (in Chinese)

[4] Cui Li-jie, Gong Xiao-ping. Fuzzy reliability optimization designing of planetary gear transmission[J]. Journal of Mechanical Transmission, 2007, 31(5): 51-52. (in Chinese)

[5] Zhou Qi-cai, Li Jing, Yu Jing. Comparison between conventional design and optimal design for planetary gear reducers[J]. Chinese Journal of Construction Machinery, 2007, 5(3): 308-312. (in Chinese)

[6] Wang Jian-hong. Study on the dynamic of flexible multibody of wind turbine[D]. Chongqing: Chongqing University, 2009. (in Chinese)

[7] Liu Xiao-su. Coupling dynamics research of hydraulic excavator slewing transmission mechanism-working device system[D]. Nanning: Guangxi University, 2011. (in Chinese)
