CNC Machine Model of Epicycloid Bevel Gear and Cutting Experiment Based on Formate Method

Abstract:

Based on formate cutting principle of epicycloid bevel gear, the cutter head is studied, and the formate cutting mathematical model with cradle structure is established, and the theoretical equation of tooth surface is derived, and the tooth flank deformation quantity caused by the changes of machine setting parameters is calculated. According to the relative motion and position relation between cutter and workpiece, the CNC formate machine for manufacturing epicycloid bevel gears is developed, and the machine model is established, and the machine setting parameters are solved according to models equivalence relation. Finally, a cutting experiment is conducted, and the influence of machine setting parameters variation on tooth flank deformation are analyzed, and it will provide theoretical direction for tooth flank correction.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 1157-1162
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.1157
• Online since: June 2012
• Authors: Shao Wu Nie, Xiao Zhong Deng, Jian Xin Su
• Keywords: CNC Machine Model, Epicycloid Bevel Gear, Formate Cutting, Tooth Flank Deformation

References

[1] N.Y.Wu: Automobile Technology and Material. (2008), p.49(In Chinese)

[2] X.Z. Dong: Journal of Mechanical Transmission. Vol.23(1999), p.29(In Chinese)

[3] J.Tang, S.Q.Yu and Z.Y. Wang: Journal of Mechanical and Electrical Enginerring. Vol.28(2011), p.1045(In Chinese)

[4] W.Q. Zhang, X.D. Guo and M.D. Zhang: Manufacturing Technology and Machining Tool. (2011), p.109(In Chinese)

[5] Q. Fan: Journal of Mechanical Design, Transactions of the ASME. Vol.129(2007), p.31

[6] M .Vimercati: Mechanism and Machine Theory. Vol.42(2007), p.668

[7] Beijing Gear Company, Ltd: Spiral Bevel Gear(Science Technology Press,China 1974).(In Chinese)
