A 16Kb SRAM with Programmable Replica Bitlines for Dynamic Voltage Scaling Systems

Abstract:

The SRAM applied to dynamic voltage scaling systems has a problem that the differential voltage of the bitlines (ΔV_BL) increases as the supply voltage rises with the conventional replica bitlines technique, and the increased ΔV_BL degrades the SRAM performance and dissipates more power. In this paper, a programmable replica bitlines technique is presented to resolve the problem. With the new technique we acquired bitline discharge time reduction up to 25.3% at the cost of 0.6% area penalty in a 16Kb SRAM. The 16Kb SRAM test chip is fabricated by using 65nm low leakage technology. Testing results show that the maximum operational frequency of the SRAM is improved from 4.3% to 9.5% under the voltage range of 0.8V~1.4V comparing with the conventional one. The operating frequency of the SRAM with proposed technique is from 440MHz at 0.8V to 1.62GHz at1.4V.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 416-422
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.416
• Online since: June 2012
• Authors: Ming Qiang Qiu, Na Bai, Jian Meng, Jun Ning Chen
• Keywords: Dynamic Voltage Scaling, Replica Bitlines Technique, SAE, Sense Amplifier (SA), SRAM
