Wear Life Prediction for a Large Diameter Spool Valve

Abstract:

Life prediction for a component can’t instead of its life tests, even so it has a very important guiding significance for the optimization design and material selection of the component, and it can decrease great loss caused by design mistakes, also possibly avoid detours, especially on initial development stage. It also is an important stage of the lifecycle design of a component. According to a certain working condition, this paper predicts the wear life of a large diameter hydraulic directional spool valve with 2-position 4-way for the hydraulic system of a high speed winch, combined with the surface micro-topography of the valve body and spool, and influence factors to the fit clearance changing caused by wear, such as shaping form errors, lateral force, matching materials, hydraulic medium and so on. The result shows that the wear life of the large diameter spool valve is more than 10 million times. The prediction provides a theoretical basis for the independent development of this valve, and has a certain reference for the design of this kind of components.

• Periodical: Advanced Materials Research (Volume 544)
• Pages: 88-93
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.544.88
• Online since: June 2012
• Authors: Kui Xia, Shu Dong Yang, Ting Lei, Liang Wu
• Keywords: Large Diameter Spool Valve, Life Prediction, Linear Wear Degree, Wear Life

References

[1] Shudong Yang, Yuanchun Zhou, Bo Luo, Sang Li, and Wenjie Tang: Design and research of a hydraulic control system for a high speed winch, Hydraulic and Pneumatic, Vol. 6(2011), p.81–83.

[2] Shizhu Wen, and Ping Huang: Tribological Principle, 3rd ed. Tsinghua University Press, Beijing, 2008.

[3] Cola Gailes Ki: Friction, Wear and Lubrication Handbook, Vol. 1. Mengsheng Yu, and Yongwei Wu translated, Machinery Industry Press, Beijing, 1986.

[4] Chunyi Sun, Bin Shi: Establishment and analysis of the wear-calculating model for single screw extruder, Food and Machinery, Vol. 27, No. 1(2011), pp.78-80.

[5] Chaoming Jin: Hydraulic Fluid Mechanics , National Defense Industry Press, Beijing, 1994.

[6] Shudong Yang, and Cunxin He: Hydraulic and Pneumatic Transmission, 3rd ed. Huangzhong University of Science and Technology Press, Wuhan, 2008.

[7] Zhuangyun Li, Hydraulic Components and System, 2nd ed. Machinery Industry Press, Beijing, 2005.

[8] Jiashu Sun: Metal Wear, Metallurgical Industry Press, Beijing, 1992.

[9] Hao Xu: Mechanical Design Handbook, 2nd ed. Vol.1, Machinery Industry Press, Beijing, 2001.
