Non-Grid-Connected Wind Power DC Network Study Based on Hybrid Convertor

Abstract:

Applying non-grid-connected wind power to high energy consuming industry has broad development prospects. This paper presents a compound DC power transmission net to realize high efficiency and reduce the loss. This net consists of current source converter (CSC) based on naturally commutated thyristor and voltage source converter (VSC) based on IGBT. Super capacitor connected to the load side stabilizes the wind power fluctuation. The coordinated control strategy of wind power, energy storage device and load is provided. Simulation results based on real wind power shows the validity of the system.

• Periodical: Advanced Materials Research (Volumes 546-547)
• Pages: 295-300
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.546-547.295
• Online since: July 2012
• Authors: Hui Fang Liu
• Keywords: CSC, DC Network, Non-Grid-Connected, Super-Capacitor (SC), VSC, Wind Power

References

[1] China Meteorological Administration, http: /www. cma. gov. cn/qhbh/newsbobao/201001 /t20100111_ 56404. html.

[2] Han Minxiao, Gui Junli, Yao Shujun, et, Frequcency control for a Power system with large amounts of wind power, Automation of Electric Power systems, Vol 32 No. 1, Jan 10 (2008).

[3] Zhao Haixiang, Studies on Voltage Fluctuation and Flicker Caused by Integrated Wind Power. Doctor Thesis, Oct, 2004. China EPRI.

[4] Weidong Gu, New strategy for the development of the wind power industry in China and the wind power non-grid-connection theory. Beijing: Chemical Industry Press, (2006).

[5] Weidong Gu, Non-grid-connected wind power: A choice for wind power development in China. " China, s Wind Power, (2006).

DOI: 10.1109/wnwec.2009.5335768

[6] Shanshui Yang; Xiaojin Lin; Zhiyong Cheng; Li Wang; Chunying Gong, An image on architecture of non-grid-connected wind system based on DC transmission, World Non-Grid-Connected Wind Power and Energy Conference, 2009. WNWEC 2009, 24-26 Sept. (2009).

DOI: 10.1109/wnwec.2009.5335773

[7] S. Meier, S. Norrga, and H. -P. Nee, New Voltage Source Converter Topology for HVDC Grid Connection of O_shore Wind Farms, in Proceedings of the 11th International Power Electronics and Motion Control Conference, EPE-PEMC , 04, Riga, Latvia, September (2004).

DOI: 10.1080/09398368.2004.11463554

[8] Peter Jones, Lars Stendius, The Challenges of Offshore Power System Construction – Troll A, Electrical Power Delivered Successfully to an Oil and GasPlatform in the North Sea, EWEC (2006).

DOI: 10.1049/cp:20060016

[9] Pan Wulue, Loss evaluation and reduction approaches for VSC-HVDC systems, Doctor dissertation, Zhejiang University, April (2008).

[10] Zhang Wenliang, Tang Yong, Zeng Nanchao; Multi-Terminal HVDC Transmission Technologies and Its Application Prospects in China; Power System Technology; 2010, 34(9): 1-6.

[11] Yuan xufeng, Research on Theory of Novel Hybrid Multiterminal HVDC System and Some Key Problems, Doctor dissertation, Huazhong University of Science and Technology, May (2007).
