Design of Electric Vehicle Battery Management System Based on CAN Bus

Abstract:

This paper is concerned about the problem of improving the service life of lithium battery and guaranteeing the safety of battery managing system (BMS) based on optimizing the process of charge, or discharge of lithium battery. Firstly, distribution method is adopted in the BMS to collect the temperature and voltage of the battery. Secondly, stage management is given to avoid over charge, or discharge of battery. Furthermore, based on LPC11C14 microprocessor, the charging device is designed. Finally, experiments are provided to show usefulness and effectiveness of the proposed methods.

• Periodical: Advanced Materials Research (Volumes 546-547)
• Pages: 272-277
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.546-547.272
• Online since: July 2012
• Authors: Ru Chun Wen, Shu Ren Han, Ling Liang
• Keywords: BMS, BQ24085 Device, CAN Bus, EV, LPC11C14

References

[1] X.Z. Wei: Automotive Electronics, 2006 (7), p.17. (In Chinese).

[2] Z.Z. Ye: Single Electric Vehicle Battery Management System (MS, Zhejiang University, China 2004), p.20. (In Chinese).

[3] J.J. Lei, Q.H. Li and L.P. Chen: Power Technology, 2010(34), p.11. (In Chinese).

[4] Moore S.W. and Peter J. S: A Review of Cell Equalization Methods for Lithium Ion and Lithium Polymer Battery Systems，SAE2001.

[5] Z.Y. Liu, L. Qi, J.K. Dai and Y. Li: Research on Li-ion Battery Management System. Acta Scicentiarum Naturalum Universitis Pekinesis. 2006(S1), p.21. (In Chinese).

[6] Nasser H. Kutkut， Life Cycle Testing of Series Battery Strings With Individual Battery Equalizers，EVS-18.

[7] .H.X. Shen, D.M. W.L. Zhu. and W.X. Chen: Charge Equalization for series Connected Battery Strings，ICEMI, October 2009(4), p.1032. (In Chinese).
