Motion Trajectory Simulation and Measurement of the 5000V Electromagnetic Repulsion Mechanism (ERM)

Abstract:

Successful applications of the ERM depend on accurate simulation models. Firstly, we built up a model on the 5000 volts ERM with ansoft. Then we measured motion trajectories of the ERM prototype respectively by means of a piezoelectric acceleration transducer, a magnetic grating displacement transducer and a linear displacement sensor. Based on the comparative analysis of the results from simulation and measurement, we concluded that the simulation model was reliable on one hand, and on the other hand by means of a linear displacement sensor along with a magnetic grating counterpart, we could obtain accurate motion trajectories with a relative error less than 5%.

• Periodical: Advanced Materials Research (Volumes 546-547)
• Pages: 368-373
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.546-547.368
• Online since: July 2012
• Authors: Jin Wu, Jin Wu Zhuang, Yong Hua Zhuang, Jun Lu
• Keywords: Acceleration, ERM, Linear, Magnetic Grid, Motion Trajectory, Simulation
