An Interchangeable Turning Sprue Bushing in a Multi Cavity Family Injection Mold

Abstract:

Interchangeable Turning Sprue Bushing (ITSB) is a small insert at the centre of core side used to change runner directions for injecting 2 different products in a separate injection mold by shifting the melt filling to the cavities. The development of ITSB is significant in cutting down cost and time consumed during fabrication of a multi cavity family mold. In this study, the tensile and flexural test pieces were designed using CAD Solidwork. The test pieces analysis was performed using CAE Cadmould simulation in order to observe the melt flow of four multi cavities family mold incorporated without and with ITSB insert. The Cadmould simulation was used specifically to analyse the melt filling, temperature distribution and volume shrinkage of the test pieces. The simulation result demonstrated that ITSB is a useful insert that can be used to overcome problems encountered in the family mold system by balancing the melt filling, minimize temperature distribution and reduced the differential of volume shrinkage of the test piece manufactured. ITSB also reduced the frequent defects formed during production such as short molding, flashing and warpage.

• Periodical: Advanced Materials Research (Volume 548)
• Pages: 600-604
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.548.600
• Online since: July 2012
• Authors: Rozana Mohd Dahan, Saiful Bahri Mohd Yasin, Zakaria Razak, Mohd Helmi Omar
• Keywords: Family Mold, Injection Molding, Mold Design, Multi Cavity Mold, Optimization

References

[1] W. Strauss, H. Valley, U.S. Patent No.: 3, 550, 207. (1970).

[2] T.D. Graham, U. S Patent 4, 260, 348. (1981).

[3] H. Takeuchi., U.S. Patent No.: 5, 374, 183. (1994).

[4] H.P. Park, B.O. Rhee and B.S. Cha: Variable-runner System for Family Mold Fillng Balance Trans Tech Publications, Switzerland: Volume 116-117, Pages 96-101 (2006).

DOI: 10.4028/www.scientific.net/ssp.116-117.96

[5] W.M. C Ivan, M. Pinfold, C.K. Kwong and W. H Szeto: A Review of Research, Commercial Software Packages and Patents on Family Mould Layout Design Automation and Optimisation the International Journal of Advanced Manufacturing Technology 57(1): 23-47 (2011).

DOI: 10.1007/s00170-011-3268-8

[6] S. Chianrabutra, A. Wongsto and T. Sirithanapipat: Balancing gate and runner systems for a family mold using CAE tools.

[7] C.S. Li and Y. K. Shen: Optimum design of runner system balancing in injection molding submitted to International Communications in Heat and Mass Transfer 22(2): 179-188. (1995).

DOI: 10.1016/0735-1933(95)00003-8

[8] E. Gaitzsch and K. Klamt: Balancing a family mould 94(8): 138-142. (2004).

[9] R.I. Irani, S. Kodiyalam and D. O Kazmer: Runner System Balancing for Injection Molds using Approximation Concepts and Numerical Optimization proceeding paper from the 18th Annual ASME Design Automation Conference. (1992).

DOI: 10.1115/detc1992-0129

[10] L.A. Vanderberg, U.S. Patent No.: 5208053. (1993).

[11] D.O. Kazmer: Injection Mould Design Engineering. 155~156, Hanser Verlag Publisher. (2007).
