The Influence on Brittle of Microstructure of Laser Quenching/Nitriding Layer

Abstract:

Have studied microstructure of the gas nitriding layer and the laser quenching/ nitriding layer using the X-ray diffractometer and the transmission electron microscope to the brittl of nitriding layer. The results show that the content of Fe3N in composite nitrided layer increased from 14.74% to the 69.45%, while the crisp hard ξ-Fe2N content dropped from 79.95%to 25.03%, Especially the Cr2N particles are much finer and the depth of the nitrided layer increases. There have phase relation, coherence and compatibility between γ'-Fe4N and α-Fe. spherical particles of cementite was formed in lower strip bainite, while the γ′ of gas nitriding diffusion layer is big, the carbide assumes the long strip off and with distributing certain directivity. Brittleness of laser hardening/ nitriding layer reduces.

• Periodical: Advanced Materials Research (Volume 549)
• Pages: 548-552
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.549.548
• Online since: July 2012
• Authors: Yi Yuan Cheng, Cheng Qiang Wang, Zi Zhen Chen, Yong Jun Niu
• Keywords: Laser Quenching, Microstructure, Nitriding

References

[1] W Moller, S Parascandola, T Telbizova, et al. Surface processes and diffusion mechanisms of ion nitrided of stainless steel and aluminium[J]. Surface and Coatings Technology, 2001, 136(1-3): 73-79.

DOI: 10.1016/s0257-8972(00)01015-x

[2] Zhong Minlin，Liu Wenjin．Leading areas and hot topics on global laser materials processing research[J]．Chinese journal of lasers，2008，35(11)：1653~1659.

DOI: 10.3788/cjl20083511.1653

[3] A A Peligrad, E Zhou, D Morton, et al. Transient temperature behaviour and dynamic process models in laser surface melting of clay tiles[J]. Surface and Coatings Technology, 2003, 150(1): 15-23.

DOI: 10.1016/s0257-8972(01)01509-2

[4] Bei Duohui，Lu Jian，Gu Jianfeng et al．Effects of surface nanocrystal lization pro-treatment on gas nitrided behavior of mildsteel[J]．Transaction of materials and heat treatment，2002，23(1)：19~24.

[5] Xi Shoumou，Zhang Jianguo，Sun Xiaoyan et al．Laser quenching + nitrided compound treatment of 38CrMoAlA steels[J]．Chinese journal of lasers，2004，31（6）：761~764.

[6] Wang Xue qian，Cao Huirong．Compounds (ε, γ ') layer in the nitriding and nitrogen carbon permeation[J]．Sichuan Industrial Institute of Technology, 2001, 20(3)48-51.

[7] Xie Shanxiao et al．Chemical treatment translation set [M]. Beijing: National Defence Industry Press, 1981, 22-23.

[8] ZhouShangqi，Houqiong，Renqin. Microstructure of 38CrMoAl steel with ion nitrogen [J]. Heat Treatment of Metals, 2002, 27(10): 10-12.

[9] Gao Yukui ， Influence of surface deformation on microstructure and properties of processing 32Cr3MoVA nitride steel[J]. Materials and Heat Treatment, 2006, 26(1): 74-76.

[10] J G. Buijnsters, P. Shankar, J. Sietsma, et. al. Gas nitriding of chromium in NH3–H2 atmosphere[J]. Materials Science and Engineering, 2003, 341(1-2): 289-295.

DOI: 10.1016/s0921-5093(02)00231-9

[11] Chu Zuoming ，Chen Yunbo，Zhang Fucheng. Advanced ultra-fine processing technology in the iron and steel materials[J]. Heat Treatment of Metals, 2004, 29(1): 16-23.

[12] Xu Zuyao. The impact of stress on bainitic transformation in steel[J]. Acta Metallurgica Sinica, 2004, 40(2): 113-119.

[13] Cui Zhongxi. Metallurgy and Heat Treatment [M]. Beijing: Mechanical Industry Press. 1993, 286.
