Differential Equation and Analytic Computation of Throttle Slice Deformation under Micro-Circle Pressure

Abstract:

It has been a key problem that the analytical computation of a throttle slice deformation, for the design of shock absorber valves parameters. In this paper, the mechanics model of throttle slice under a spring pre-tightening was simplified into that under a micro-circle pressure. Using boundary and continuity constraints, the general equation for throttle-slice deformation under a micro-circle pressure was given, and by mathematical transformation, an analytical formula was established. With the practical example, the deformation of throttle slices on spring pre-tightening force at any radius was computed, and was testified by ANSYS. It is known that the results computed are close to that simulated, and the deviation is only 6.6 mm. It is shows that the method of deformation analysis of a throttle slice under micro-circle pressure is reliable, which has important reference value for throttle valves parameters design and characteristic simulation of shock absorbers.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 1146-1149
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.1146
• Online since: August 2012
• Authors: Chang Cheng Zhou, Lei Lei Zhao, Hong Yan Li
• Keywords: Analytic Computation, Deformation, Micro-Circle Pressure, Spring Pre-Tightening Force, Telescopic Shock Absorber, Throttle Slices

References

[1] A.K. Samantaray. Modeling and analysis of preloaded liquid spring/damper shock absorbers. Simulation Modeling Practice and Theory. 17(2009), pp.309-325.

DOI: 10.1016/j.simpat.2007.07.009

[2] Zhou Changcheng, Zhao Lihang, Gu Liang. Study on superposition throttle-slices of damper. Transactions of Beijing Institute of Technology, 26(2006), 681-684.

[3] Chen Yong, He Hui, Bai Jinfu. Analysis of hydraulic shock absorber spring valve chip deformation of charade car. Automobile Technology, 31(2000), pp.19-21.

[4] Babak Ebrahimi, Mir Behrad Khamesee, M. Farid Golnaraghi, Design and modeling of a magnetic shock absorber based on eddy current damping effect. Journal of Sound and Vibration. 315(2008), pp.875-889.

DOI: 10.1016/j.jsv.2008.02.022

[5] Jeung-Hoon Leea, Kwang-JoonKim. A method of transmissibility design for dual-chamber pneumatic vibration isolator. Journal of Sound and Vibration . 323(2009), pp.67-92.

DOI: 10.1016/j.jsv.2008.12.028

[6] Zhou Changcheng, Gu Liang, Wang Li. Bending deformation and coefficient of throttle-Slice. Transactions of Beijing Institute of Technology. 26(2006), pp.581-584.

[7] Zhou Changcheng, Gu Liang. Superposition throttle-slices opening size and characteristic test of telescope-damper. Chinese Journal of Mechanical Engineering. 43(2007), pp.210-215.

DOI: 10.3901/jme.2007.06.210

[8] Xu Zhilun. Elastic mechanics. Beijing: Higher Education Press(1990).

[9] Lu Mingwan, Luo Xuefu. Basic theory of elastic mechanics. Beijing: Peking University Press (1990).
