A Performance Model for U-Tube Ground-Coupled Heat Exchanger

Abstract:

Because of the great advantages of savings for installation costs and areas of the ground, the ground source heat pump (GSHP) system combined with the ground-coupled heat exchanger with structural member is becoming more and more popular such as energy pile foundation etc.. However, the calculation method especially on the perspective of plate-type ground-coupled heat exchanger (PGHE) has not been established. This paper reports a study on a mathematical model developed to analyze the heat transfer of U-tube plate-type ground-coupled heat exchanger (UPGHE) which combined with structural member and an analytical solution is revealed. The results show that there are clear ‘heat submerge’ for the leg with lower temperature of UPGHE and it is more sensible to arrange one leg apart from another. The results also show that the spacing of pipes have obvious impact on the performance of UPGHE and the temperature difference between two legs have no important effect on the total performance of UPGHE.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 1404-1408
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.1404
• Online since: August 2012
• Authors: Gang Ming, Ye Tian, Cai Chu Xia
• Keywords: Analytical Solution, Plate-Type Ground-Coupled Heat Exchanger (PGHE), U-Tube Plate-Type Ground-Coupled Heat Exchanger (UPGHE)

References

[1] Monique de Moel, Peter M. Bach, Abdelmalek Bouazza, Rao M. Singh, JingLiang O. Sun: Technological advances and applications of geothermal energy pile foundations and their feasibility in Australia. Renewable and Sustainable Energy Reviews, vol. 14, p.2683–2696, (2010).

DOI: 10.1016/j.rser.2010.07.027

[2] Yi Man, Hongxing Yang, Nairen Diao, Junhong Liu, Zhaohong Fang: A new model and analytical solutions for borehole and pile ground heat exchangers. International Journal of Heat and Mass Transfer, vol. 53, p.2593–2601, (2010).

DOI: 10.1016/j.ijheatmasstransfer.2010.03.001

[3] Laloui L, Nuth M, Vulliet L: Experimental and numerical investigations of the behavior of a heat exchanger pile. Int J Numer Anal Meth Geomech 2006; 30: 763–81.

DOI: 10.1002/nag.499

[4] A. Haji-Sheikh, J.V. Beck: Temperature solution in multi-dimensional multi-layer bodies . International Journal of Heat and Mass Transfer, vol. 45, p.1865–1877, (2002).

DOI: 10.1016/s0017-9310(01)00279-4

[5] M. N. Ozisik, translated by Changming Yu: Heat Conduction. Advanced Education Press, 1st edition, (1992).

[6] H. Salt: Transient conduction in a two-dimensional composite slab – I. Theoretical development of temperature modes. International Journal of Heat and Mass Transfer, vol. 26, p.1611–1616, (1983).

DOI: 10.1016/s0017-9310(83)80080-5

[7] M.D. Mikhailov, M.N. Ozisik: Transient conduction in a three-dimensional composite slab . International Journal of Heat and Mass Transfer, vol. 29, pp.340-342, (1986).

DOI: 10.1016/0017-9310(86)90242-5

[8] Ling Yan, A. Haji-Sheikh, J.V. Beck: Thermal characteristics of two-layered bodies with embedded thin-film heat source. ASME J. Electron. Vol. 115, pp.276-283, (1993).

DOI: 10.1115/1.2909329

[9] F. de Monte: Transient heat conduction in one-dimensional composite slab. A natural, analytical approach. International Journal of Heat and Mass Transfer, vol. 43, pp.3607-3616, (2000).

DOI: 10.1016/s0017-9310(00)00008-9

[10] K. D. Cole: Heat Conduction Using Green's Functions . CRC Press, 2nd edition, (2011).
