Design and Simulation Analysis of 1000KN·m Backstop

Abstract:

In this article, the Pro/Engineer virtual prototyping technology is used for three dimensional entity modeling, assembly, and simulation analysis of 1000KN·m large backstop in four design plans to confirm the integrity and assembling of backstop. By using the ANSYS/LS-DYNA software, it makes numerical simulation analysis of the backstop in non-return process, and through the analysis comparison to the simulation result, it obtains the optimization design plan of the 1000KN·m backstop.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 1438-1441
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.1438
• Online since: August 2012
• Authors: Li Hua Fu, Juan Juan Jiang, Dai Xing Zhang, Hai Quan Li, Hua Song, Cheng Zhong Yu
• Keywords: Backstop, Finite Element, Numerical Simulation

References

[1] Xueping Liu. Development trend of large belt conveyor and control drive system. Coal mine machinery, 2000, 11: 1-2.

[2] Runzhi Niu. Large tilt upon delivery belt conveyor non-return and brake. Lifting transportation machinery, 2008, 9: 84-87.

[3] Jichun Zhang, Bin Xu, Bo Lin. Pro/e Wildfire structure analysis. Beijing: mechanical industry press, (2004).

[4] Jianghong Sun, Hong Gao. Pro/e structure analysis and movement simulation. Beijing: China railway press, (2004).

[5] Chaohui Zhang. ANSYS12. 0 structure analysis engineering application analytical examples. Beijing: mechanical industry press, 2010, 1.
