The Liquid Level Measuring Device in Truck Based on ZigBee

Abstract:

Because of the separation of modified truck’s cab and car tank, there must set long wires to transmit the signal. A liquid level measuring device for truck is designed and developed in this article. Using the ZigBee technology, a wireless data transmit mode, including the hardware and the software, is realized. A compensation and correction method is discussed on the basis of the ultrasonic transmission theory. This device has a simple structure, high precision, low cost, easy to install and so on.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 2002-2006
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.2002
• Online since: August 2012
• Authors: Hai Bo Lin, Ji Xin Zhou, Hui Cao, Nian Teng Feng, Chui Jie Yi
• Keywords: Error Correction, Liquid Meter, Ultrasonic, ZigBee

References

[1] Hwang K S, Chen Y J, Hong H C. Autonomous Exploring System Based on Ultrasonic sensory Information. Journal of Intelligent and Robotic System. 2004, 39(3): 307-331.

DOI: 10.1023/b:jint.0000021069.90242.de

[2] Ma Wei. Error Analyze and Compensation of Ultrasonic Liquid Level Meter. Electronic Sci. & Tech. 2011, 24(4): 108-109.

[3] Wang Chao, Pan Weihua: A Scheme on Ultrasonic Level Meter Design. Journal of Nanjing University(Engineering and Technology Edition). 2010, 10(3): 44-46, 63.

[4] Wendi Rabiner Heinzelman, Anantha Ch, Hari Balakrichnan. Energy-efficient Communication Protocol for wireless Microsensor Networks. Proceeding of the 33rd Hawaii International Conference on System Sciences. Washington DC: IEEE Computer Society, (2000).

DOI: 10.1109/hicss.2000.926982
