A Novel 5-Axis Machining Method for Sculptured Surface

Abstract:

In this work, a novel method for sculptured surface subdivision to improve the machinery’s ability and efficiency in 5-axis CNC machining complex surface is introduced. The method subdivides automatically a monolithic convex or concave or simultaneously complex sculptured surface into a number of surface patches and achieves the goal of similar normal directions and small difference between the curvatures in every patch by using weight fuzzy cluster algorithm which takes the curvatures and normal vectors of the sculptured surface into account simultaneously. The inclination angle variation between every two Cutter Contact Points (CC Points) is decreased in every patch to avoid large-angle rotation of tool to save machining time when a flat-end mill is used. This work contributes to automated 5-axis CNC tool path generation for sculptured part machining and forms a foundation for further research.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 855-860
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.855
• Online since: August 2012
• Authors: Si Kun You, Xiao Chu Liu, Hong Guang Deng, Jun Liu
• Keywords: 5-Axis, Curvature Direction, Fuzzy Cluster, Normal Direction, Surface Subdivision

References

[1] Y. J. Wang, et al., A 3D curvature gouge detection and elimination method for 5-axis CNC milling of curved surfaces, The International Journal of Advanced Manufacturing Technology, vol. 33, pp.368-378, (2007).

DOI: 10.1007/s00170-006-0825-7

[2] Y. J. Wang, et al., Euler-Meusnier sphere based milling cutter model for curvature gouge avoidance in curved surface machining, in Society of Manufacturing Engineers, Monterrey, Mexico, 2008, pp.249-257.

[3] B. K. Choi, Surface Modeling for CAD/CAM, Elsevier, New York, (1991).

[4] I. D. Faux and M. J. Pratt, Computational Geometry for Design and Manufacture , Ellis Horwood, West Sussex, UK, (1979).

[5] Fuzzy Logic Toolbox User's Guide., (2008).

[6] MATLAB 2009b User's Guide., The Mathworks, Inc, (2009).

[7] Information on http: /www. mathworks. com.
