Research on Nonlinear Control of AC Active Magnetic Bearings

Abstract:

For the five degree-of-freedom (5-DOF) AC active magnetic bearing (AMB), which is a multivariable, nonlinear and strongly coupled system, conventional single-variable controller cannot meet the control requirements. Based on the state space model of 5-DOF AC AMB and direct feedback linearization, the equations of coordinate transform and nonlinear state feedback can be simplified into differentiating output equations, which achieves the input-output linearization of 5-DOF AC AMB system. Then, the system can be decoupled into five independent 2-order linear subsystems and realizes the completely decoupling of 5-DOF. Finally, the internal model control (IMC) method is employed to synthesize the subsystems, in order to avoid the performance deteriorated due to the model error and external disturbance. The results of simulation example demonstrate that this decoupling control strategy can realize not only the dynamic decoupling of 5-DOF AC AMB, but also the good dynamic/static performance and robustness.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 968-974
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.968
• Online since: August 2012
• Authors: De Hong Zhu, Rong Xu, Li Hu Lu, Hai Juan Liu
• Keywords: Active Magnetic Bearing (AMB), DOF, Internal Model Control, Mathematical Models

References

[1] Schweitzer G., Traxler A, Bleuder H, Active Magnetic Bearings: Basis, Properties, and Applications of Active Magnetic Bearing, Zurich: vdf Hochschulverlag AG and ETH Zurich, (1994).

[2] Fukata S, Yutani K, Characteristics of Electromagnetic Systems of Magnetic Bearings Biased with Permanent Magnets, in Proc 5th International Symposium on Magnetic Bearings, Massachusetts, pp.234-243, (1998).

DOI: 10.1299/jsmec.41.206

[3] Mcmullen P T, Huynh C S, Hayes R J, Combination Radial-axial Magnetic Bearing, in Proc 6th International Symposium on Magnetic Bearings, Zurich, pp.473-478, (2000).

[4] Zhu Dehong, Wang Peng, Chen Xing, The principle and Decoupling Control of Innovative Three-pole AC Magnetic Bearing, 2010 International Conference on Intelligent Computation Technology and Automation, Changsha, China, vol. 3, pp.874-877, May (2010).

DOI: 10.1109/icicta.2010.205

[5] Li Chunwen, Feng Yuankun, Inverse System Method for Multivariable Nonlinear Control, Beijing: Tsinghua University Press, (1991).

[6] Ma Youjie, Direct Feedback Linearization Theory and Static Var Compensation for Nonlinear Control, Beijing: Tstinghua University, (1993).

[7] Song Fuhua, Deng Enhui, Nonlinear Internal-model Control Based on Support Vector Machine, Control Theory & Applications, vol. 25, no. 6, pp.1065-1070, (2008).

[8] Zhu Huangqiu, Parameter Design and Control System Study for Active Magnetic Bearing in the Axial Direction of Bearingless Motors, Transactions of China Electrotechnical Society, vol. 17, no. 3, pp.12-16, (2002).

[9] Wen Bangchun, et al, Higher Rotor Dynamics-theory, Technology and Applications, Beijing: China Machine Press, (2000).
