Design of Composite Brakes Using Knowledge-Based Design Methodology

Abstract:

In designing modern friction materials that are normally made of composite materials, a more systematical approach is needed in order to select the most appropriate composition of raw materials for specific applications. Here, knowledge-based design methodology has been formulated for composite brake design application, that consists of: design database generation from experiments, metamodelling, and global optimization processes. The objective function has incorporated, among others, the uncertainties introduced in the experimentally-obtained design database, so that providing the optmization results with the information of variation. The application of the methodology has been demonstrated to two cases, i.e. train brake and motorcycle brake pad, with the optimization results close to the targetted values and the information of output variation, as intended.

• Periodical: Advanced Materials Research (Volume 566)
• Pages: 324-330
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.566.324
• Online since: September 2012
• Authors: Rachman Setiawan, E. Yulianto
• Keywords: Composite Brake, Design Optimization, Knowledge-Based Design

References

[1] D. Chan, and Stachowiak , G. W., Review of automotive brake friction materials, Proc. Institution Mechanical Engineer vol. 218, pp.953-965, (2004).

[2] Jang, H., Lee, J.S. and Fash, J.W., Compositional effects of the brake friction material on creep grown phenomena,. Wear, 2001. 251: pp.1477-1483.

DOI: 10.1016/s0043-1648(01)00786-4

[3] Yulianto, R. Setiawan, R. Suratman, Influence of Particle Properties to The Gross Composite Friction Material Characteristics, Proc. 12th Int. Conf. on Quality in Research, Bali, Indonesia, 4-7 July (2011).

[4] CAFS - SIU, Center For Advance Friction Studies Research Areas,. Available on: http: /frictioncenter. engr. siu. edu/rArea2. html#, accessed on Des (2011).

[5] R. Setiawan, Composite Plate Mechanical Characterisation through Dynamic Test, PhD. Dissertation, University of Southampton, UK, (2004).

[6] D. Lim, Y.S. Ong, R. Setiawan and M. Idris, Classifier-assisted Constrained Evolutionary Optimization for Automated Geometry Selection of Orthodontic Retraction Spring, Proc. 2010 IEEE Congress on Evolutionary Computation Proc., Barcelona, 18-23 July, (2010).

DOI: 10.1109/cec.2010.5586460

[7] G. G. Wang and S. Shan, Review of Metamodelling Techniques in Support of Engineering Design Optimization, Journal of Mechanical Design, (2006).

[8] D. Lim, Evolutionary Optimization for Computionally Expensive Problems, PhD Thesis, Nanyang Technological University, Singapore, (2009).

[9] PT Kereta Api (Persero), Specification for Passanger Car Composite Brake (in Bahasa Indonesia), (2009).

[10] JIS D441-1993, Classification Class 4, Brake Linning and Pads for Automobiles.

[11] ISO 6310-1981, Road Vehicles-Brake linnings-Compressibility-Test Procedure.
