The Dynamic Analysis of Concrete Pump Truck Arm in Civil Engineering

Abstract:

The concrete pump truck integrates transportation with pouring process ，which is characterized with flexibility, facility and celerity in civil engineering. As for the concrete pump truck, the arm system is the most important because the rationality of the arm directly influences the performance and pouring position of the truck in its application in civil engineering. For the arm system of the concrete pump truck, the movement of the arm system and the hydraulic cylinder are analyzed respectively with multi-body dynamic theory. By using numerical arithmetic to resolve the dynamic equation, the terminal track of the arms is analyzed. It shows that the kinetic equation built by multi-body dynamics can describe the dynamic characteristics of pump truck exactly.

• Periodical: Advanced Materials Research (Volume 568)
• Pages: 138-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.568.138
• Online since: September 2012
• Authors: Li Dai, Yun Gong Li, Yu Liu, Jian Wang
• Keywords: ARM, Civil Engineering, Concrete Pump Truck, Multibody Dynamics (MBD)

References

[1] Guozhong Zhang. The Construction Industry Publishing Company. Beijing,China, (2004)

[2] Liu Jie, Dai Li. 12th World Congress in mechanic and mechinery, Vol. 5, (2007) Besançon (France), p.129

[3] Min Ye, Longxiang Xiao. The Tianjin University Publishing Company, (2001) p.140, Tianjin, China

[4] Youfang Lu, The Higher Education Publishing Company, Beijing,(1996). P.1

[5] Ahmed A. Shabana. Multibody System Dynamics 1, (1997),p.189.

[6] R.G. Langlois, R.J. Anderson. Multibody System Dynamics 3, (1999). P.109

[7] Guangfu Sun. Mechanism and mechine theory, Vol. 38 (2003), p.1489
