Scattering of Two-Dimensional Sea Surface at Low Grazing Angles with Physical Optics Method

Abstract:

As the classic analytical methods cannot calculate the electromagnetic scattering characteristics at Low Grazing Angle (LGA), a novel numerical method is presented by utilizing the Radar Cross Section (RCS) of the low grazing two-dimensional PM sea spectrum based on the triangles-based Physical Optics (PO) method in this paper. The calculated RCS is compared with the numerical calculation method of different targets and frequencies of incident wave. The results show that PO method is more accurate, especially under LGA condition, and it has a better agreement with the results calculated by commercial software FEKO.

• Periodical: Advanced Materials Research (Volume 571)
• Pages: 372-376
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.571.372
• Online since: September 2012
• Authors: Zhuo Chen, Zhen Sen Wu, Yong Zhang, Jun Jing Xue, Wen Hua Ye
• Keywords: Low Grazing Angle, Physical Optics Method, Radar Cross Section

References

[1] E. Bahar and B. S. Lee., Radar scatter cross sections for two-dimensional random rough surfaces-Full wave solutions and comparisons with experiments, Waves in Random Media, vol. 6, p.1~23 (1996).

DOI: 10.1080/13616679609409792

[2] R. J. Burkholder, Low angle scattering from 2-D targets on a time-evolving sea surface, IEEE Transactions on Geoscience and Remote Sensing, vol. 40, pp.1185-1190, (2002).

DOI: 10.1109/tgrs.2002.1221954

[3] B. E, Scattering Cross Sections for random rough surfaces: Full wave analysis, Radio Science, vol. 16, pp.331-341, (1981).

DOI: 10.1029/rs016i003p00331

[4] J. T. Johnson and R. T. Shin, A Numerical Study of the Composite Surface Model for Ocean Backscattering, IEEE Transactions on Geoscience and Remote Sensing, vol. 36, pp.72-83, (1998).

DOI: 10.1109/36.655319

[5] M. Born, Principles of optics: electromagnetic theory of propagation, interference and diffraction of light, Cambridge Univ Pr, (2000).

[6] R. J. Burklioltler, Fat Physical Optics Integration for Rough Surface Scattering, IEEE, pp.392-395, (2003).

[7] J. C. West, Effect of Shadowing on Electromagnetic Scattering from Rough Ocean Wavelike Surfaces at Small Grazing Angles, IEEE, vol. 35, No. 2, pp.293-301, (1997).

DOI: 10.1109/36.563269

[8] R. J. Burkholder, A Monte Carlo Study of the Rough-Sea-Surface Influence on the Radar Scattering from Two-Dimensional Ships, IEEE Antennas and Propagation Magazlne, vol. 42, pp.25-32, (2001).

DOI: 10.1109/74.924601

[9] M. El-Shenawee, Scattering from multiple objects buried beneath two-dimensional random rough surface using the steepest descent fast multipole method, IEEE Trans. Antennas Propag, vol. 51, p.802~809, 2003, 4.

DOI: 10.1109/tap.2003.811096

[10] J. T. Johnson, On the canonical grid method for two-dimensional scattering problems, IEEE Trans. Antennas Propag, vol. 46, p.297~302, 1998, 3.

DOI: 10.1109/8.662647
