Research on Harmonic Response of Hydraulic Screwdown System on Modern Hot Rolling Mill

Abstract:

In this paper, the dynamic mathematical model about the asymmetric three-potential four-way valve control asymmetric hydraulic cylinder is established, and a hot rolling mill hydraulic screwdown system simulation model is constructed to research the dynamic characteristics by MATLAB/Simulink. It is obtained that the displacement output curve of the hydraulic cylinder by changing the rolling different strip thickness. Finally contrasting the input and output spectrum curve, it found that given the vibration signal by hydraulic system can transfer to the hydraulic cylinder. At the same time it indicate that the computer simulation is the effective way that research the dynamic characteristics of the hydraulic screwdown.

• Periodical: Advanced Materials Research (Volume 572)
• Pages: 203-209
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.572.203
• Online since: October 2012
• Authors: Qi Hui Ling, Xiao Qiang Yan, Yi Fang Zhang
• Keywords: Asymmetric Hydraulic Cylinder, Asymmetric Servo Valve, Harmonic Response

References

[1] M.R. I, R and J: 6th International Conference on Electrical and Computer Engineering (Dhaka, Bangladesh, December 18-20, 2010). Vol. 7, p.275.

[2] C.L. Wang, F. Ding and J.P. Li: Chinese Journal of Mechanical Engineering, Vol. 15 (2004) No. 6, p.471.

[3] C.Y. Ma, J. Ye: Hydraulic Servo Control System (Coal Industry Publishing House, China 1990).

[4] Y.X. Lu: Electro-hydraulic Proportional Control Technology (Higher Education Press, China 1988).

[5] S.Y. Yan: Sensor Application of Technology (Science Publishing House. China 2008).

[6] Z.L. Wang, S.K. Wang: Matlab/Simulink and Control System Simulation (Electronics Industry Press China 2009).
