A Vehicle Heading and Attitude Measurement System Based on Earth Magnetic Field Sensor

Abstract:

Measurement method is studied utilizing vertical gyroscopevertical gyroscopevertical gyroscope, static earth magnetic field sensor and CPU. According to electromagnetism induction law, when a wire loop incises the magnetic force line of the earth magnetic field, it will bring about the induction electromotive force, the earth magnetic field can be calculated by signal processing of induced voltage in measuring coil. A heading and attitude measuring system to vehicle are designed, the heading precision were raised. Experiment data states clearly the heading precision is not more than 0.5°. This system can be used to detect heading and attitude, and can be extended easily.

• Periodical: Advanced Materials Research (Volumes 588-589)
• Pages: 1140-1143
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.588-589.1140
• Online since: November 2012
• Authors: Hao Hu
• Keywords: CPU, Earth Magnetic Field Sensor, Measurement, Vertical Gyroscope

References

[1] Jie gao, Xue-feng wei, Ning zhang, Zhi-xu lu: Mathematics Model and Error Correcting of a Solid State Navigation Sensor. Metrology and Measurement Technique, 2009(3), pp.1-2.

[2] Ning zhang, Chun-sheng lin, Xue-liang pang: Solid Geomagnetic field Vector Detector Based on Low power Chip. Journal of Detection & Control, 2009(6), pp.28-30.

[3] Wei ma, Lian-xun zeng, Zhi-hua jin: Algorithm of deviation calibrating for digital magnetic compass. Electronic Measu rement Techn ology, 2007(11), pp.74-77.
