Based on LabVIEW Resistance Method Temperature Testing for Traction Transformers and Motor Winding

Abstract:

Temperature is an important parameter for the characterization of the transformer and the motor running. Winding temperature test according to the actual operation of the traction transformer and motor temperature protection device requirements, in-depth study, temperature test of the traction transformer based on virtual instrument and traction motor winding resistance method, the method using LabVIEW to develop test software, respectively, for data acquisition, data playback, data analysis and processing, data file management functions, and temperature test equipment, not only real-time test system, but also post-processing the data after the test, in order to analysis of the factors that affect the temperature of the windings. Validity of the method is proved by experiments.
