Study of Energy Saving Lamp System for Sound and Light Double Control

Abstract:

The main content of intermittent lamp energy saving technology study in small public places is the circuit control system. A lamp energy saving control circuit system is developed and designed by using the timer 555 modules, Silicon controlled technology, power supply circuit, photosensitive and audio sensor module, etc. The system has sound and light double control and timing function, photosensitive and audio sensing circuit dormancy and lamp shut off during the day or light is good. In the evening or subtle lighting, photosensitive and audio sensors are opened at the same time, lamp working for 20 seconds through the human voice incentive and automatically shut off. The application and test show that the system circuit has low power consumption and strong generality promotion, and realizes the purpose of energy saving.

• Periodical: Advanced Materials Research (Volume 590)
• Pages: 222-226
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.590.222
• Online since: November 2012
• Authors: Zeng Lin Zhang, Pu Te Wu, Xiao Qing Yu
• Keywords: Control, Delay Circuits, Energy Consumption (EC), Light, Sound

References

[1] Z. Li, K. Zhang and Z. Yiten: Research paper collection on China's Energy and Environment, China Environmental Press, Beijing, (2000).

[2] L. De-Sousa and B. Bouchez: Rethink the Electrical Vehicle Architecture, Automotive Power Electronics International Conference and Exhibition, (2011).

[3] Y. Bong-Gi: Optimization of Powder Core Inductors of Buck-Boost Converters for Hybrid Electric Vehicles, IEEE VPPC, (2009), 730-735.

DOI: 10.1109/vppc.2009.5289776

[4] J.S. Chiang, T.H. Chang and P.C. Chou: Low distortion and swing suppression sigma–delta modulator with extended dynamic range scheme, Analog Integrated Circuits and Signal Processing, (2005), 169-182.

DOI: 10.1007/s10470-005-4010-y

[5] P.R. Sanchez, E. Acha, J.E.O. Calderon, V. Feliu and A.G. Cerrada: A versatile control schem for a dynamic voltage restorer for power-quality improvement, IEEE Trans. Power Del. (2009), 277-284.

DOI: 10.1109/tpwrd.2008.2002967

[6] B. Aman and G. Ciobanu: Timed Mobile Ambients for Network Protocols, Springer, Heidelberg, (2008), 234-250.

[7] G. Ciobanu and M. Koutny: Modelling and Verification of Timed Interaction and Migration, Springer, Heidelberg, (2008), 215-229.

[8] M.A. Vieira, P. Louro, M. Vieira, A. Fantoni and A.S. Garçao: Light-activated amplification in Si-C tandem devices: A capacitive active filter model, IEEE Sensors Journal, (2011).

DOI: 10.1109/jsen.2011.2176537

[9] M.A. Vieira, M. Vieira, J. Costa, P. Louro, M. Fernandes and A. Fantoni: Double pin Photodiodes with two Optical Gate Connections for Light Triggering: A capacitive two phototransistor model. Sensors & Transducers Journal 9, (2010), 96-120.

DOI: 10.1109/sensordevices.2010.32

[10] J.H. Lee, H.G. Jeon and K.I. Kim: Design of a redundancy control circuit for 1T-SRAM repair using electrical fuse programming, J the Korean Institute of Maritime Information and Communication Sciences, (2010), 1877-1886.

DOI: 10.6109/jkiice.2010.14.8.1877
